Sky Blue Double Twist Copper Wire Bunching Machine Cable Twisting Machinery
Sky Blue Double Twist Copper Wire Bunching Machine Cable Twisting Machinery
Sky Blue Double Twist Copper Wire Bunching Machine Cable Twisting Machinery
Sky Blue Double Twist Copper Wire Bunching Machine Cable Twisting Machinery
Sky Blue Double Twist Copper Wire Bunching Machine Cable Twisting Machinery
Sky Blue Double Twist Copper Wire Bunching Machine Cable Twisting Machinery
Sky Blue Double Twist Copper Wire Bunching Machine Cable Twisting Machinery
Sky Blue Double Twist Copper Wire Bunching Machine Cable Twisting Machinery
Specifications
Stranding Area :
0.35-6.0mm2
Max Speed :
2000rpm (4000 twist)
Application :
Electrical, automobile wires
Brand Name :
Fuchuan
Model Number :
FC-650B-6
Certification :
CE
Place of Origin :
China
MOQ :
1set
Price :
USD27650
Payment Terms :
T/T, L/C
Supply Ability :
500SETS PER YEAR
Delivery Time :
45days
Packaging Details :
simply packed
Color :
sky blue / apple green
Main Motor Power :
7.5KW
Wire Diameter :
0.15-1.04mm
Core Wire Dia :
0.5-3.0mm
Tension Control :
Touch screen + PLC
Fit for bobbin :
DIA 630mm
Fit copper wire :
0.12mm-0.52mm
Fitable Wire :
core wire,bare copper wire,tinned wires,silver jacketed wires
operation mode :
touch screen
also wire :
enamelled wire / bare copper wire
Twist Type :
Double twist
Pitch Range :
11.6-100mm, 34 zones
Description

China FUCHUAN Copper Wire Bunching Machine , Double Twist Bunching Machinery

Quick Details:

A Japan Technology, product in China

B FUCHUAN® Series Model B normal wire high speed bunching machine and double twist bunching machine.

C New arrival, mainly apply for stranding the electrical wire and automobile wire and other small section area conductor.

Characteristics:

a. With high rotation speed, with constant tension from empty bobbin to full bobbin, with superior quality for twist wire,

b. Only need to change the capstan wheel to change the pitch.

c. Easy to operate.

d. The machine is driven by synchronization strap.

Specifications:

Equipment models FC-650B-6
Twisting usage Apply for the twisting of aerospace, medical equipment, cellphone and ultra conductor(above seven pcs of bare copper wires, tinned wires, silver jacketed wires and enameled wires),double twisting for core wires.
Single wire dia(mm) φ0.15-φ1.04
Stranding section area (mm²) 0.35-6.0
Core wire single wire dia φ0.5-φ3.0
Core wire stranding outer dia φ1.0-φ6.0
Pitch(mm) 11.6-100(34zones)
Direction of lay Optional for right or left
Outer dia*bore*outer width

φ630*φ56*475

φ630*φ127*475
Max rotating speed 2000(4000twist)
Main motor power 7.5KW
Inverter power 7.5KW
Tension control method Touch screen +PLC+ magnetic powder clutch, it may ensure the constant tension from empty bobbin to full bobbin
Magnetic powder clutch 5kgf
Protection Machine will automatically brake when wire inside and outside is broken, the machine will automatically stop when the preset length is arrived.
Brake mode Electromagnetic brake
Traversing method Rolling ring drive units, winding pitch and breadth are adjustable

Other Information

FOB SHANGHAI
Payment

TT, L/C
Delivery

FOB Shanghai/Ningbo
Origin

China
Minimum Order

1 set
Package
with container
