3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed
3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed
3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed
3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed
3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed
3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed
3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed
3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed
Specifications
Brand Name :
WINLEY
Model Number :
S-3750/13.2
Certification :
UL/cUL,CE,ISO
Place of Origin :
CHINA
MOQ :
1unit
Price :
$5000-$150000
Payment Terms :
T/T
Supply Ability :
1000set/month
Delivery Time :
30days
Packaging Details :
Plywood case
Phase :
Three Phase
Capacity :
3750KVA
Primary Voltage :
13.2KV
Secondary Voltage :
480Y/277
Vector Group :
YnYn0
Efficiency :
99.00%
Efficiency Standard(s) :
DOE 2016
Cooling Class :
KNAN; Self-Cooled
Description

3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed

WINLEY specialize in the production of three phase pad mounted transformers. Our products have obtained UL/cUL certification comply with ANSI, IEEE, DOE, CSA and other standards. The rated power is usually 75kva to 5500kVA, and the voltage can reach 34.5 kV.

3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed

Main data

Transformer Type Pad Mounted, Compartmental-Type
Transformer Configuration Liquid Filled Pad Mounted
Transformer Feed Type Loop Feed
Operation Step-Down Operation (Not Approved for Step-Up)
Phase Three Phase
Capacity 3.75 MVA (3750 KVA)
Vector Group YnYn0
Primary Voltage 13200V
Secondary Voltage 480Y/277
Frequency 60 Hz
Temperature Rise 65°C
Insulation Rating Class E Insulation - 120°C, 248°F
Cooling Class KNAN; Self-Cooled
Impedance (Typical) 5.0-7.5%
Efficiency Standard(s) Meets DOE 2016 Standards, Meets CSA Standards Meets ANSI/IEEE Standards
K-Factor Rating (Harmonic Mitigation) K-1 (Standard)
Winding Material Copper
Ambient Temperature Rating 40°C
Ambient Operating Temperature Range -40°C to +40°C (-50°F to +104°F)
Sound Level 64 dBA
Elevation (Altitude) 3300ft (1000 meters) Above Sea Level

structure

3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed

Standard Feature

− Mild steel, optional stainless steel tank
− Three-point latching door for security
− Removable sill for easy installation
−Stainless steel cabinet hinges and mounting studs
Bolted-on cabinet with removable sill having the following depths:
19"dedp for 300kva through 750 kva
22"deep for 1000kva through 1500 kva
24"deep for 2000kva through 3750kva
30"deep for 5000kva through 7500kva
− Live front construction & dead front construction
− Steel HV/LV compartment barrier
− Oil drain plug for 500 kVA and below
− 1” drain valve with sampler for 750 kVA and above

Specification

Three Phase Pad Mounted Transformer
Rated Power (KVA) High Voltage (KV) Low Voltage (V) Loss (W)
No-load Loss (W) On-load Loss (W)
75KVA 24.94/14.4kV
12.47/7.2kV
34.5KV/
19.92KV/
13.8KV/
13.2KV/
or others		 120/240V
480Y/
277V
600Y/
347V		 180 1250
112.5KVA 200 1500
150KVA 280 2200
225KVA 400 3050
300KVA 480 3650
500KVA 680 5100
750KVA 980 7500
1000KVA 1150 10300
1500KVA 1640 14500
2000KVA 2160 20645
2500KVA 2680 23786
3000KVA 3300 25300
3750KVA 4125 27875
5000KVA 5200 30000

Technical drawings

3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed

Production process

3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed

3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed

3 Phase Pad Mounted Distribution Transformer 3750 Kva 13.2KV Dead Front Loop Feed

FAQ

1. Q: Can I have a sample order?

A: Yes, we welcome sample order to test and check quality.

2. Q: What is the lead time?

A: Mass production time 15-25 days.

3. Q: How long is the warranty?

A: 24 monthes from B/L. If there are any accessory problems,just provide the photos of damaged accessory,then we will provide free service. According to the number of products,we will provide easily damaged accessories for free. we also can provide technical support if you need.

4. Q: Is OEM/ODM available?

A: Yes,it is! We are manufacturer with our own R&D team, we can customize products according to customer's drawing or requirements.

Customized services:

a. Customized color and special function.

b. Customized box.

c. Print customer's logo.

d. Your other ideas about product, we can help you design and put them into production. The above customized services must be confirmed before production.

5. Q: How to control the products quality?

A: Our company owns the core technology ,all kinds of products hold CE certificate. We have professional engineers. Workers are strictly required to make products according to the drawings. Each process has technical instructors.The QC supervisors will regularly inspect the production. We will do products performance tests during production, and comprehensive quality tests when the products is completed.
