Bolted Marine Hatch Cover Steel Rectangular Window For Boat
Bolted Marine Hatch Cover Steel Rectangular Window For Boat
Specifications
Brand Name :
Deyuan
Model Number :
DY301-330
Certification :
CCS, ABS, etc
Place of Origin :
China
MOQ :
1
Price :
USD100 to USD1000 per unit
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
500 units per month
Delivery Time :
3 to 30 days
Packaging Details :
Export packing
Part :
Hinge
Product name :
Rectangular Window
Material :
Steel, Aluminium alloy
Installation Method :
Bolted, welded
Glass THK :
12 - 20mm
Standard :
GB/T 3226-1995
Description

Bolted Marine Hatch Cover Steel Rectangular Window For Boat

Brief description:

This product is to be used as rectangular windows in the deck houses and superstructures above

freeboard deck of marine ships and naval ships and in the relative spaces of marine structures.

It can also be

used as rectangular windows of inland ships where appropriate.

Series:

N series regular series: Common rectangular windows with a toughened safety glass pane.

P series fire-resistant series: Rectangular windows used in B class fire resistant divisions.

H series heated series: Rectangular windows with an electri-heated glass pane.

Type: Heavy-type rectangular window & light type rectangular window.

Main features:

1. Type: Rectangular Window.

2. Material: Steel , Aluminium alloy.

3. Standard:ISO6042-1980.

4. Certificate: CCS , ZC , ABS , BV , RINA , KR , LR , GL , DNV.

Specification:

Series Type Nominal size
 Opening size of casing wall Fixed frame
W*h W1*h1 r W2*h2 W3*h3
N

P

H		 1 300*425 352*477 76 348*473 430*555
2 355*500 407*552 76 403*548 485*630
3 400*560 452*612 76 448*608 530*690
4 450*630 402*682 126 498*678 580*760
5 500*710 552*762 126 548*758 630*840
6 560*800 612*852 126 608*848 690*930
7 900*630 952*682 126 948*678 1030*760
8 1000*710 1052*762 126 1048*758 1130*840
9 1100*800 1152*852 126 1148*848 1230*930

Product's photo:

Bolted Marine Hatch Cover Steel Rectangular Window For Boat

Bolted Marine Hatch Cover Steel Rectangular Window For Boat
