Low Speed Weigh In Motion System with Quartz Sensor for 0.5-40 km/h Speed Range and -40°C to 85°C Operation
Low Speed Weigh In Motion System with Quartz Sensor for 0.5-40 km/h Speed Range and -40°C to 85°C Operation
Specifications
Brand Name :
HENGLIANG
Model Number :
ZQS-40-SY
Place Of Origin :
CHINA
Certification :
ISO
MOQ :
1 SET
Price :
USD20000-35000
Packaging Details :
Wooden Box
Delivery Time :
5-10 Days
Payment Terms :
T/T
Supply Ability :
30 Sets/month
Operatingtemperaturerange :
-40°C To 85°C
Sensor :
Quartz Sensor
Dataoutput :
Real-time Weight Data
Weightcapacity :
Up To 30 Tons Per Axle
Speed :
0.5~40km/h
Power :
AC 220V
Operatingtemperature :
-40°C To 85°C
Weighing Accuracy :
90%~95%
Description
Speed 0.5 to 40km/h Low Speed Weigh In Motion Equipment
Product Overview

The Low Speed Weigh In Motion (WIM) system is an advanced and reliable solution designed to accurately measure vehicle weights at low speeds. Engineered with precision and durability, this system is ideal for applications where accurate weight measurement is critical, including toll stations, traffic monitoring, and vehicle enforcement.

The system features a compact design (1000mm * 300mm * 50mm) with quartz sensor technology, operating voltage of AC 110V~220V, and can measure vehicle weights at speeds ranging from 0.5 km/h to 40 km/h. It operates reliably in extreme temperatures from -40°C to 85°C.

Technical Specifications
Parameter Specification
Product Name Low Speed Weigh In Motion
Dimensions 1000mm * 300mm * 50mm
Measurement Range 0.5-40 km/h
Sensor Type Quartz Sensor
Working Voltage AC 110V~220V
Communication Interface RS232/RS485
Weight Capacity Up to 30 tons per axle
Data Output Real-time weight data
Operating Temperature -40°C to 85°C
Applications

The HENGLIANG Low Speed WIM system (model ZQS-40-SY) is designed for various applications requiring accurate vehicle weight measurement at low speeds:

  • Highway and toll station monitoring for weight regulation compliance
  • Logistics and freight yards for continuous vehicle weight monitoring
  • Industrial and construction sites for heavy machinery weight measurement
  • Border crossings and controlled access points
Support & Services

Our comprehensive support package ensures optimal system performance:

  • Technical support for installation, calibration, and system integration
  • Routine maintenance and on-site inspections
  • User training sessions and software updates
  • Customized solutions for specific project requirements
Packaging & Shipping

Each Low Speed WIM system is securely packaged for safe transportation:

  • Custom protective casing with high-density foam inserts
  • Durable corrugated cardboard outer box with clear handling instructions
  • Trusted courier services with tracking options
  • Detailed packing list and user manual included
  • Special arrangements available for bulk orders and international deliveries

Delivery typically within 5-10 days. We recommend inspecting packages upon receipt and contacting customer support immediately if any issues are found.
