IP65 Infrared Vehicle Lane Separator with 1.6m Height and Aluminum Alloy Shell for Truck Scales
IP65 Infrared Vehicle Lane Separator with 1.6m Height and Aluminum Alloy Shell for Truck Scales
Specifications
Working voltage :
AC 220V 50Hz
The vibration :
0~100Hz
Protection grade :
IP65
Automatic defrost working :
< 2A
The shell :
Aluminum Alloy oxidation spray, heating glass windows
Brand Name :
Hengliang
Model Number :
HLG16A
Certification :
ISO
Place of Origin :
China
MOQ :
1 SETS
Price :
USD 800-8000/SET
Payment Terms :
T/T
Supply Ability :
300 PCS/Month
Delivery Time :
5~7days
Packaging Details :
Wooden box
Type :
Vehicle identification system
Description
IP65 Infrared Road Traffic Lane Separator 1.6m Height For Truck Scales
Product Overview

This infrared vehicle lane separator is designed specifically for truck scales and weighing systems. The system consists of two components - an infrared transmitter and an infrared receiver - to automatically separate and identify vehicle information with high precision.

Technical Specifications
Parameter Specification
Working Voltage AC 220V 50Hz
Working Current Automatic defrosting not working: ≤0.4A
Automatic defrost working: < 2A
Separation Accuracy 99.9% (Sunny conditions)
≥ 99.5% (Rain, snow, or fog conditions)
Minimum Detection Object Width 105mm
Maximum Detection Distance 10M
Output Forms I/O real time serial output trigger; shielding position, fault location and output
Data Interface RS485 serial interface; baud rate 9600/19200/38400bps
Protection Grade IP65
Height 1.6m
Shell Material Aluminum alloy oxidation spray, heating glass windows
Working Environment -40 ~ +70℃ (temperature)
0 ~ 95%RH (humidity)
Lightning protection and grounding resistance ≤4Ω
Anti-light Interference Ability > 50000 Lux
Key Features
  • High-precision vehicle separation with 99.9% accuracy
  • Robust IP65 protection rating for outdoor use
  • Wide operating temperature range (-40°C to +70°C)
  • Excellent anti-light interference capability
  • Durable aluminum alloy construction
  • Automatic defrosting functionality
  • Multiple data interface options
