Specifications
Brand Name :
Wisdom Battery
Model Number :
WD-BSS08-ADAPTIVE
Place of Origin :
China
MOQ :
5
Price :
2150USD-3000USD
Payment Terms :
T/T
Supply Ability :
30days/30PCS
Delivery Time :
30days
Packaging Details :
Paper box packaging
Structural material :
Sheet metal
Thickness :
1.5mm
Appearance processing :
Spray coating
Structural optimization :
Continuous optimization
Single compartment load-bearing capacity :
<30KG
Number of slots :
8
Number of rechargeable batteries :
8
Socket configuration :
Corresponding charging contact components are equipped in each slot
Single compartment clear space dimensions :
126*181*353 (W*H*D)
Battery dimensions :
126*171*330
Cabinet dimensions :
550*1826*610 (W*H*D)
Input voltage :
AC 220V
Maximum power capacity of the entire machine :
5700W
Maximum charging power per cell :
950W
Maximum charging current :
12.5A
Applicable battery model :
72V lithium battery
Standby power :
<50W
Speaker (1) :
8R 3W
Electric meter :
Single-phase electric meter
Smoke detector :
Real-time monitoring, intelligent power cut-off, intelligent alarm
Fire protection :
Real-time monitoring, intelligent power cut-off, starts when there is a fire
Storage temperature :
-20°C to 70°C
Operating temperature :
0°C to 50°C
Humidity :
5% to 75% without condensation
Cooling method :
Air cooling
Operating environment :
Indoor, Outdoor (Outdoor installation is recommended with a canopy)
Description

The shared battery swap cabinets address the major safety hazards, battery fragility, short range and difficult charging issues faced by electric vehicle users. Through product iteration and upgrading, they replace the traditional "charging" mode with the "battery swapping" model.
The intelligent cloud system monitors the current, voltage, power and environmental status of the charging terminals in real time. In case of any abnormalities, it immediately alerts, effectively preventing potential safety hazards. Users can find nearby stations through the cabinet interface or the APP, and achieve barcode-based battery swapping and intelligent battery recognition.
The entire system is uniformly controlled by the cloud platform, supporting real-time configuration of battery swapping and charging strategies, ensuring the stable operation of the battery swap cabinets in different environments.
1.Door-type hard connection, convenient battery replacement + rear hook lock
2.4G network, main control, power protection system
3.IPX4 protection level
4.Intelligent warehouse control design
5.Intelligent charger, intelligent charging strategy
6.Real-time monitoring
7.Single-bin automatic fire extinguishing system
8.Independent battery guide rail system
9.Built-in UPS to enable battery replacement in case of AC power failure
10.Real-time communication with battery BMS, cloud intelligent management and data analysis, fault alarm
11.Intelligent charging status indicator light
12.Intelligent cloud platform, APP for viewing nearby stations
13.Intelligent control of single-bin power, limiting the total power of the entire cabinet to not exceed the upper limit
14.Support for remote software upgrade, support for remote switching, remote disabling, and enabling of individual bins
