T-connector suitable for mated with power distribution systems or surrounding power supply branch box. It can effect multi-way of power supply from 600A high-voltage bushing, Tee rear connector, Multi-way junction, 600A loadbreak bushing. T-connector w/capacitive test point, rated current is 600A, suitable for conductor cross section is 35-500 mm2.

-The T-II connector is the combination of Loadbreak Bushin Extender and T Deadbreak Connector ,It suitable for 600A cable , and mate with 200A Loadbreak Elbow Connector at spare joint to increase input line

-

Connects two or more 600A bolted Tee Connectors for use as a separable cable joint or for connection of multiple cables to an Apparatus Bushing .

-

The 630A insulated protective cap should provided insulating function for energy bushing. It also should provided protective dirty and waterproof function for without electrification bushing. It can mated with bushing and multi-junction. It need provided 630A insulated cap to sealing spare junction when it mated with 630A multi-junction.

-

It suitable for cable branch box with SF6 Switchgear , the design is made to be flexible to mate with different connection demand , and differentiate in European and American . it provide two, three or four 200A loadbreak and 600A deadbreak,15KV mixed interfaces on one side that are internally bused together and meet all requirements of ANSI/IEEE 386-Separable Insulated Connector Systems. There is a shed-mount terminal on the other side typically used for bus connection. The Specific Junctions are molded using high quality peroxide-cured EPDM insulation. When mated with a comparably rated product, the junction provides a fully shielded, fully insulated.

-

The front or end connector are suitable for branch box, pad-mounted transformers and surround power supply branch box..etc. suitable for conductor cross section is 35-400mm².

-

-

It can connect with Shielded Fore-Connector , and the spare joint can be mated with HBLQ-17/50 Screen Rear Connector Arrester

-

It suitable for branch box ,surround power supply branch cabinet of European style, it can mate with 630A Shielded Fore-Connector

-

-

It suitable for branch box with SF6 switchgear. It can mate with 630A connector of European style.

-

-

-

It apply for high voltage input line of padmounted transformers and surround power supply branch box. It should mate with 630A Shielded Fore-Connector.

-

-

-

Connects two or more 600A- bolted Tee Connectors for use as a separable cable joint or for connection of multiple cables to an Apparatus Bushing .

-

-

-
