Specifications
Place of Origin :
Shanghai, China
Brand Name :
wenyou
Model Number :
9205L
MOQ :
20
Price :
$2.80-3.80
CAS No. :
1675-54-3
Molecular Formula :
C21H24O4
EINECS No. :
216-823-5
Epoxy Value :
4.5 - 5.0Eq/kg
Resin Viscosity :
7500 - 13000mPa.s
Resin Density :
1.16 - 1.20g/cm3
Resin Vapor Pressure :
< 0.01Pa
Resin Flash Point :
around 135℃
Hardener Viscosity :
200 - 400mPa.s
Hardener Density :
1.17 - 1.24g/cm3
Hardener Vapor Pressure :
around 0.5Pa
Hardener Flash Point :
around 140℃
Epoxy Resin :
LE-9205L 100 pbw
Hardener :
LH-9205L 100 pbw
Flexibilizer :
LF-660 0-20 pbw
Description
Product Description
High Performance Cast Resin for Dry Type Transformers: Exceptional Insulation and Durability
In the realm of electrical power distribution, dry type transformers play a crucial role. And the quality of the cast resin used in these transformers is of utmost importance. Our high - performance cast resin is specially formulated for dry type transformers. It offers exceptional insulation properties, which are essential for preventing electrical leakage and ensuring safe and efficient operation. Made with advanced materials and manufacturing techniques, this cast resin has remarkable durability. It can withstand harsh environmental conditions, such as high humidity and temperature fluctuations. In industrial settings where dry type transformers are exposed to dust and chemicals, our cast resin - protected transformers maintain their integrity. The resin forms a strong and stable barrier around the transformer windings, enhancing the overall performance and lifespan of the dry type transformer. Whether it's for commercial buildings, power plants, or industrial facilities, this high - performance cast resin is the ideal choice for dry type transformers, providing reliable insulation and long - lasting durability.

*Brief Introduction

LE-9205L is a liquid solvent-free modified bisphenol A type epoxy resin.

LH-9205L is a liquid modified carboxylic anhydride hardener with an added accelerator.

LF-660 is a low-viscosity solvent-free modified polyol.

*Formulation

Epoxy resin LE-9205L 100 pbw
Hardener LH-9205L 100 pbw
Flexibilizer LF-660 0-20 pbw
Filler Silica powder 350-420 pbw
Color paste LC series * 3 pbw

*Properties

Excellent resistance to thermal shock, superior mechanical and dielectric properties.

*Processing Methods

- Conventional gravity casting process under vacuum.
- Automatic pressure gelation process (APG).
- Production process is adjustable according to client’s present production methods.
Applications

Indoor electrical insulators for medium and high voltage applications, such as insulators, dry-type transformers, and other insulation products.

*Sample application image

Epoxy Resin for Dry Type Transformers High Insulation Cast Resin

Advantages

Epoxy Resin for Dry Type Transformers High Insulation Cast Resin

Certifications

Epoxy Resin for Dry Type Transformers High Insulation Cast Resin

Packaging & Shipping

*Package

20kg/iron pail or 220kg/iron barrel or 1200kg/plastic tank

Epoxy Resin for Dry Type Transformers High Insulation Cast Resin

*Shipment

Epoxy Resin for Dry Type Transformers High Insulation Cast Resin

FAQ

1.What's the usage of your product?

Our product is epoxy resin raw material, for making medium and high voltage electrical power insulation parts, such dry type transformers, potential transformers(PT), current transformers(CT), voltage transformers(VT), insulators, wall bushings, solid sealed pole, insulation covers, etc.

2.What's the MOQ of your product?

MOQ of our product is 20kg pail as sample for a trying.

3.What's the price of your product?

We have developed a series of material system to satisfy various of insulation parts applied to different environment situations. So our price is flexible depends on the material type, current pricing of market, order quantity, price terms, and payment terms.

4.What's the most convenient way to confirm suitable material type for my products?

The best way to confirm is to provide clear photos of your terminal products, and remark its application environment as Indoor or Outdoor? And also remark its producing process as APG or Casting?
