Specifications
Place of Origin :
Shanghai, China
Brand Name :
wenyou
Model Number :
LW-9425A/B
MOQ :
20
Price :
$2.60-3.50
CAS No. :
1675-54-3
Molecular Formula :
C21H24O4
EINECS No. :
216-823-5
Resin Viscosity :
20000 - 40000mPa.s
Resin Density :
1.95 - 2.70g/cm3
Resin Vapor Pressure :
≤ 0.01Pa
Resin Flash Point :
around 135℃
Hardener Viscosity :
10000 - 20000mPa.s
Hardener Density :
2.0 - 3.0g/cm3
Hardener Vapor Pressure :
around 0.5Pa
Hardener Flash Point :
around 140℃
Epoxy Resin Type :
Modified BPA
Hardener Type :
Modified carboxylic anhydride
Mixing Ratio :
100:100 pbw
Processing Methods :
Gravity casting, APG
Description
Product Description
Fast - Curing Cast Resin for Dry Type Transformers: Boosting Production Efficiency
In the manufacturing of dry type transformers, time is money. Our fast - curing cast resin is a game - changer for transformer manufacturers. It significantly reduces the curing time compared to traditional resins, allowing for faster production cycles. The fast - curing process is highly efficient, enabling manufacturers to produce more dry type transformers in a shorter period. This not only increases productivity but also helps in meeting tight project deadlines. Despite its fast - curing nature, the resin does not compromise on quality. It provides excellent adhesion to the transformer windings and other components, ensuring a strong and durable bond. The resulting dry type transformers have high mechanical strength and reliable electrical performance. The fast - curing cast resin is easy to handle and process, even in large - scale production. It can be used in various manufacturing methods for dry type transformers, such as vacuum casting. With this resin, manufacturers can streamline their production processes, reduce costs, and gain a competitive edge in the market.

*Brief Introduction

LW-9425A is a modified BPA (bisphenol A) type epoxy resin with aluminum oxide powder.

LW-9425B is a modified carboxylic anhydride hardener with aluminum oxide powder.

*Formulation

Epoxy resin LW-9425A 100 pbw
Hardener LW-9425B 100 pbw

*Properties

Two-component saturated cyclic epoxy resin system with pre-mixed fillers, slurry liquid at room temperature.

Excellent resistance to thermal shock with superior crack resistance.

*Processing Methods

- Conventional gravity casting process under vacuum.
- Automatic pressure gelation process (APG).
- Production process is adjustable according to client’s present production methods.
Applications

For medium and high voltage electrical insulation applications, such as 66-220KV GIS bowl-type insulators and other insulation components.

*Sample application image

Fast-Curing Epoxy Resin for Dry Type Transformers LW-9425A/B

Advantages

Fast-Curing Epoxy Resin for Dry Type Transformers LW-9425A/B

Certifications

Fast-Curing Epoxy Resin for Dry Type Transformers LW-9425A/B

Packaging & Shipping

*Package

20kg/iron pail or 220kg/iron barrel or 1200kg/plastic tank

Fast-Curing Epoxy Resin for Dry Type Transformers LW-9425A/B

*Shipment

Fast-Curing Epoxy Resin for Dry Type Transformers LW-9425A/B

FAQ

1.What's the usage of your product?

Our product is epoxy resin raw material, for making medium and high voltage electrical power insulation parts, such dry type transformers, potential transformers(PT), current transformers(CT), voltage transformers(VT), insulators, wall bushings, solid sealed pole, insulation covers, etc.

2.What's the MOQ of your product?

MOQ of our product is 20kg pail as sample for a trying.

3.What's the price of your product?

We have developed a series of material system to satisfy various of insulation parts applied to different environment situations. So our price is flexible depends on the material type, current pricing of market, order quantity, price terms, and payment terms.

4.What's the most convenient way to confirm suitable material type for my products?

The best way to confirm is to provide clear photos of your terminal products, and remark its application environment as Indoor or Outdoor? And also remark its producing process as APG or Casting?
