CE Thermal Transfer Overprinters Bluetooth Plastic Packaging Printing Machine
CE Thermal Transfer Overprinters Bluetooth Plastic Packaging Printing Machine
CE Thermal Transfer Overprinters Bluetooth Plastic Packaging Printing Machine
CE Thermal Transfer Overprinters Bluetooth Plastic Packaging Printing Machine
Specifications
Brand Name :
Welljets
Model Number :
T8120
Certification :
CE
Place of Origin :
Shanghai
MOQ :
1 units
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
10 units per day
Delivery Time :
7 work days
Packaging Details :
Carton Packing
Technology :
Thermal Transfer
Print head :
Kyocera 32mm
Speed :
200 Packs/min
Controller :
Bluetooth
Description

Welljets T8130 Easy To Operate Thermal Transfer Overprinters Plastic Packaging Printing Machine

Thermal Transfer Overprinting (TTO) is a printing technique that can produce high-quality bar codes, text and images on a variety of materials including plastic films, paper and other substrates. The process begins with a ribbon that is coated with a wax or resin-based ink. The ribbon is loaded into the thermal transfer printer, which has a thermal print head that applies heat to the ribbon. When the print head is activated, the ink on the ribbon melts and is transferred to the substrate, creating a sharp, clear image. To achieve this, the product must have perfect contact with the thermal transfer printer. TTO printing is therefore primarily suitable for foils and similar materials. In addition to the ribbon, the thermal strip is also one of the typical consumables.

Advantages of Welljets Thermal Transfer Printer:

low printing costs
high durability of the print image
mature, robust and low-maintenance technology
good edge sharpness
good contrast

T8120/T8130 Thermal Transfer Overprinter

Technical Parameters:

Print area 24mm*20mm (T8120) / 32mm*20mm (T8130)
Technology Thermal transfer overprinting
Print head 24mm (T8120) and 32mm (T8130)
Resolution 203dpi (8 dots/mm) and 300dpi (12 dots/mm)
Font size 2~4mm, normal or bold
Printing speed Maximum 200 ppm
Character size Vector font can be enlarged arbitrarily (can be bold)
Character types Multi-language, numbers, punctuation, etc.
Print direction 0° or 180°
Print time 100ms (minimum stop time of packaging film)
Scope of application Intermittent packaging equipment (such as VFFS, labeling machine, etc.)
Barcode type CODE-128, CODE-39, CODE-93, ITF, EAN-8, EAN-12, UPC-A, UPC-A, QR code, etc.
Print Content Barcode, QR-code, MFG, EXP, Batch number, Real time, Inputted text, etc.
Signal input Signal: NPN/PNP type (DC12V-24V), switching type sensor
Output No contact signal
Ribbon length 300m (Outside ink)
Ribbon types Wax/resin type, resin type
Materials PVDCPET,PE,NY,CPP,OPP,BOPP,BOPET,BOPA,PE,VMPET,VMCPP, etc.
Working condition 5℃- 40℃, 10%-90%, non-condensation
IP rate IP40
Power Adapter input: AC 100-240V ±10%, 50-60Hz, output maximum current 5A
I/O port Print signal, fault relay, 0V/COM, DC 24V
