Hydrulic 20T Lifting Pipe Welding Rollers With 150mm Lifting Stroke
Hydrulic 20T Lifting Pipe Welding Rollers With 150mm Lifting Stroke
Hydrulic 20T Lifting Pipe Welding Rollers With 150mm Lifting Stroke
Hydrulic 20T Lifting Pipe Welding Rollers With 150mm Lifting Stroke
Hydrulic 20T Lifting Pipe Welding Rollers With 150mm Lifting Stroke
Hydrulic 20T Lifting Pipe Welding Rollers With 150mm Lifting Stroke
Specifications
Brand Name :
Weldsuccess
Model Number :
FIT UP - 20
Certification :
ISO / CE / CO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, L/C, D/P, Western Union
Supply Ability :
5 Sets Per Month
Delivery Time :
10 Days
Packaging Details :
Wooden Case
Max Capacity :
15 T
Adjust Way :
Bolt Adjustment / Hydrulic Lifting
Motor Power :
2 * 0.75 KW
Control Way :
Wireless Hand Control Box
Turning Speed :
0 - 1000 mm/min
Package Way :
Wooden Case
Name :
Pipe Welding Rollers
Description

15 T Hydrulic Lifting Pipe Welding Rollers With 150mm Lifting Stroke

Pipe Welding Roller / Tank Turning Rolls Description

1. Voltage: 380V 50Hz 3P to UK market.

2. Fully CE certificates supported.

3. Professional manufacturer will ensure you the best after sales service.

4. Powered rolls and Idler rolls will up / down together.

Pipe Welding Rollers Specification

Model HGK - 10 HGK - 20 HGK - 30 HGK - 40
Max Capacity 10 T 20 T 30 T 40 T
Roller Diameter (mm) 300 350 350 400
Roller Width (mm) 170 180 180 200
Working Range (mm) 300-3200 500-4500 500-4500 500-4800
Roller Speed (mm/min) 1 - 1000
Motor Power (kw) 2 * 0.55 2 * 1.1 2 * 1.5 2 * 1.5
Option : □ Bolt Adjustment □ Lead Screw Adjustment

Advantages

1. Hydrulic lifting Pipe Welding Rollers can adjust the pipe height to make sure on the same horizontal.

2. If you work outside and worry about the foundation sink, then just choose this model.

3. The favourable price performance ratio yields will ensure a quick payback of your investment.

4. We also provide tailor-made tank turning roll according to your special requirements.

Details Parts Brand On Pipe Welding Rollers

1. Danfoss / Yaskawa inverter

2. ABB / Invertek motor

3. Cable / Shuntian Reducer

4. Schneider / Siemens electric system

5. Voltage is 380V 50Hz 3P , or reset as your required

After sale service For Pipe Welding Rollers From Wuxi Success

1. We provide 12month guaranty period for the whole machine quality.

2. During this time, any issue proved because of the machine flaw itself,we would take responsibility of it.

3. Except of the guaranty period,technical advisory support is available freely covering the whole using life of the machine.

4. Engineer service on user premises is also available for necessary.

Hydrulic 20T Lifting Pipe Welding Rollers With 150mm Lifting Stroke

PLEASE SNED US YOUR INQUIRY FOR VIDEO NOW.
