Galvanized Iron Wire Hesco Barrier with Hexagonal Hole Shape and 50mm*50mm Aperture for Defense and Flood Control
Galvanized Iron Wire Hesco Barrier with Hexagonal Hole Shape and 50mm*50mm Aperture for Defense and Flood Control
Galvanized Iron Wire Hesco Barrier with Hexagonal Hole Shape and 50mm*50mm Aperture for Defense and Flood Control
Galvanized Iron Wire Hesco Barrier with Hexagonal Hole Shape and 50mm*50mm Aperture for Defense and Flood Control
Galvanized Iron Wire Hesco Barrier with Hexagonal Hole Shape and 50mm*50mm Aperture for Defense and Flood Control
Galvanized Iron Wire Hesco Barrier with Hexagonal Hole Shape and 50mm*50mm Aperture for Defense and Flood Control
Specifications
Hesco Box Size :
200x100x50 welded Hesco
Wire diameter :
5mm /6mm
Spiral wire :
4mm/5mm
Wire Gauge :
2.0-4.5mm
Hole shape :
Hexagonal
Brand Name :
Bingze
Model Number :
HB20231009
Certification :
ISO9001-2015
Place of Origin :
Anping,China
MOQ :
1 set
Price :
10 dollars
Payment Terms :
T/T,L/C
Supply Ability :
8000 Set/Sets per Month
Delivery Time :
10-15days
Packaging Details :
Usually wrapped with shrink film and packed in pallet
Aperture size :
50mm*50mm
Description
Galvanized Barrier Welded Barriers for Bastion Sand Recover Geotextile Bastion

Mil Defensive barrier/bastion is a protective wall designed to resist explosive shock waves and limit the destructive effects of explosions to a specific range. Compared to reinforced concrete hesco bastions, our barriers offer significant advantages including lighter weight, easier loading/unloading, and full recyclability and reusability.

Hesco bastions utilize the perfect combination of welded gabion wire and geotextile fabric, serving as temporary to semi-permanent levees or blast walls against explosions and small-arms fire. These defensive barriers, also known as Blast Wall Barriers or Defensive Bastions, are prefabricated multi-cellular systems constructed from Golfan/hot-dip galvanized welded gabion, lined with non-woven geotextiles.

The barriers can be filled with sand, earth, cement, or stones and are widely used in fortifications and flood control applications.

Key Features
  • Spiral-hinged corners for enhanced stability
  • Non-woven geotextile liner for optimal filtration
  • Welded mesh frame construction
  • Available in beige or green colors
Product Specifications
Model Height Width Length Internal Cells
KN-154" (1.37m)42" (1.06m)32'9" (10m)9 cells (4+5)
KN-224" (0.61m)24" (0.61m)4' (1.22m)2 cells (2*1)
KN-339" (1.0m)39" (1.0m)32'9" (10m)10 cells (5*2)
KN-439" (1.0m)60" (1.52m)32'9" (10m)10 cells (5*2)
KN-524" (0.61m)24" (0.61m)10' (3.05m)5 cells (5*1)
KN-666" (1.68m)24" (0.61m)10' (3.05m)5 cells (5*1)
KN-787" (2.21m)84" (2.13m)91' (27.74m)13 cells (4+4+5)
KN-854" (1.37m)48" (1.22m)32'9" (10m)9 cells (4+5)
KN-939" (1.0m)30" (0.76m)30' (9.14m)12 cells (6*2)
KN-1087" (2.21m)60" (1.52m)100' (30.5m)20 cells (5*4)
KN-1148" (1.22m)12" (0.30m)4' (1.22m)2 cells (2*1)
KN-1284" (2.13m)42" (1.06m)108' (33m)30 cells (5*6)
KN-19108" (2.74m)42" (1.06m)10'5" (3.18m)3 cells (3*1)
Wire Specifications
  • Wire diameter: 5mm / 6mm
  • Spiral wire: 4mm / 5mm
  • Material: Hot dipped galvanized wire / Galfan galvanized wire
  • Mesh opening: 3 inch × 3 inch
Standard Sizes
  • Height 4.5' × Width 3.5' × Length 32.8'
  • Height 3.3' × Width 3.3' × Length 32.8'
Geotextile Specifications
  • Size: 300g/400g per square meter
  • Color: Light tan / Dark green
  • Technology: Machine stitched
Product Details

Our Hesco barrier is manufactured from strengthened hot-dipped galvanized or zinc-aluminium coated steel, delivering exceptional protection and stability against various threats. We select premium thick, fire-resistant, and UV-resistant geotextiles to ensure heavy-duty performance and extended service life.

Applications
  • Perimeter security and defense walls
  • Personnel and material bunkers
  • Defensive firing positions
  • Protection engineering of seaside areas
  • Border crossing checkpoints
  • Flood control retaining walls
Company Profile

Anping Bingze Wire Mesh Products Co., Ltd. has specialized in the production and research of stainless steel wire mesh for 25 years. As an integrated manufacturer encompassing production, processing, distribution, and wholesale, our product range includes galvanized welded wire mesh, stainless steel welded wire mesh, PVC welded wire mesh, crimped wire mesh, galvanized woven wire mesh, stainless steel woven wire mesh, chain link fence, steel fence, welded wire mesh fence panels, PVC euro fence, 358 anti-climb fence, razor wire, and Hesco Barrier systems.

Since our establishment, we have maintained four core principles: High Quality, Quick Delivery, Competitive Pricing, and Thorough Service. Our commitment to product quality and business integrity has earned us favorable recognition from customers worldwide.

The company employs precision manufacturing machinery and advanced techniques, combined with scientific management methods and rigorous quality control systems. Our products meet the highest standards and are exported to numerous countries including Southeast Asia, Middle East, America, Japan, and various African nations.

Packing Details
  • Inner packaging: Plastic paper
  • Outer packaging: Wooden pallets
  • Custom packaging available upon request
Frequently Asked Questions
Q: How long is your delivery time?
A: Generally 3-7 days for in-stock items, or 15-20 days for custom orders, depending on quantity.
Q: Do you provide samples?
A: Yes, we provide product samples for testing. Samples are free, but freight charges are collected by the customer.
Q: How can I know the completion of my order?
A: Order process: Deposit payment → Production begins → Logistics information transfer → Shipment booking → Customer notified of ETD & ETA → Container loading → Balance payment → Document delivery.
Q: How can I know whether you are a reliable company?
A: We have been in business since 1987 with extensive exporting experience and hold relevant industry certifications.
