Galfan Coated Gabion Box with Hot Dip Galvanized Wire Mesh and 450 N/mm2 Tensile Strength for Stone Retention
Galfan Coated Gabion Box with Hot Dip Galvanized Wire Mesh and 450 N/mm2 Tensile Strength for Stone Retention
Galfan Coated Gabion Box with Hot Dip Galvanized Wire Mesh and 450 N/mm2 Tensile Strength for Stone Retention
Galfan Coated Gabion Box with Hot Dip Galvanized Wire Mesh and 450 N/mm2 Tensile Strength for Stone Retention
Specifications
Wire Diameter :
3-6mm
Tensile strength :
min. 450 N/mm2
Surface Treatment :
Electro galvanized, Hot dip galvanized, Galfan coated, PVC coated
Wire Material :
Hot dip galvanized, Galfan coated
Mesh Opening :
50*50,50*100,100*100
Brand Name :
Bingze
Model Number :
WGB20231009
Certification :
ISO9001-2015
Place of Origin :
Anping,China
MOQ :
1 square meter
Price :
5-15 dollars
Payment Terms :
T/T,L/C
Supply Ability :
500 Square Meter/Square Meters per Day gabion wire
Delivery Time :
10-15days
Packaging Details :
1) carton 2) pallet 3) as customer's requirement
Gabion Size :
2mx1mx1m,etc
Description
Welded Gabion Wire Mesh Box Galfan Coated Gabion Walls Gabions for Stones
Our factory chooses high-quality raw materials to ensure the safety and comfort of your supplies.
  • Low-carbon steel wire, which is protected by hot galvanizing or cold galvanizing. The thickness of galvanized protective layer is made according to customer requirements, and the normal galvanizing amount is 20-300g/m².
  • Galfan coated wire (zinc 5% aluminum or zinc 10% aluminum), with corrosion resistance more than three times that of traditional pure zinc plating, and tensile strength of the steel wire not less than 380Mpa.
  • PVC/PE galvanized steel wire, wrap a layer of PVC or PE protective layer on the surface of high-quality low-carbon steel wire to increase protection in high pollution environments, and choose different colors to blend with the surrounding environment.
  • Stainless steel wire, which has strong anti-corrosion performance.
Galfan Coated Gabion Box with Hot Dip Galvanized Wire Mesh and 450 N/mm2 Tensile Strength for Stone Retention Galfan Coated Gabion Box with Hot Dip Galvanized Wire Mesh and 450 N/mm2 Tensile Strength for Stone Retention
Can be Assembled by springs, C-rings. Reinforced by Hooks.
Product Specifications
Galfan Coated Gabion Box with Hot Dip Galvanized Wire Mesh and 450 N/mm2 Tensile Strength for Stone Retention
Gabion Model Gabion Size (m) Wire Diameter (mm) Mesh Opening (mm) Surface Treatment
BZ-01 2x1x1m 3.0-10.0mm Square mesh: 50x50 75x75 100x100 150x150
Rectangle mesh: 30X50 30X80 50X80 50X100 100X150 100X200		 Electro galvanized
Hot dip galvanized
Galfan coated (Zinc-5%Al Aluminum) (Zinc-10%Al Aluminum)
PVC coated
BZ-02 2x1x0.5m 3.0-10.0mm Square mesh: 50x50 75x75 100x100 150x150
Rectangle mesh: 30X50 30X80 50X80 50X100 100X150 100X200		 Electro galvanized
Hot dip galvanized
Galfan coated (Zinc-5%Al Aluminum) (Zinc-10%Al Aluminum)
PVC coated
BZ-03 1.5x1x1m 3.0-10.0mm Square mesh: 50x50 75x75 100x100 150x150
Rectangle mesh: 30X50 30X80 50X80 50X100 100X150 100X200		 Electro galvanized
Hot dip galvanized
Galfan coated (Zinc-5%Al Aluminum) (Zinc-10%Al Aluminum)
PVC coated
BZ-04 1x1x1m 3.0-10.0mm Square mesh: 50x50 75x75 100x100 150x150
Rectangle mesh: 30X50 30X80 50X80 50X100 100X150 100X200		 Electro galvanized
Hot dip galvanized
Galfan coated (Zinc-5%Al Aluminum) (Zinc-10%Al Aluminum)
PVC coated
BZ-05 1x1x0.5m 3.0-10.0mm Square mesh: 50x50 75x75 100x100 150x150
Rectangle mesh: 30X50 30X80 50X80 50X100 100X150 100X200		 Electro galvanized
Hot dip galvanized
Galfan coated (Zinc-5%Al Aluminum) (Zinc-10%Al Aluminum)
PVC coated
BZ-06 1x0.5x0.5m 3.0-10.0mm Square mesh: 50x50 75x75 100x100 150x150
Rectangle mesh: 30X50 30X80 50X80 50X100 100X150 100X200		 Electro galvanized
Hot dip galvanized
Galfan coated (Zinc-5%Al Aluminum) (Zinc-10%Al Aluminum)
PVC coated
BZ-07 1x0.8x0.3m 3.0-10.0mm Square mesh: 50x50 75x75 100x100 150x150
Rectangle mesh: 30X50 30X80 50X80 50X100 100X150 100X200		 Electro galvanized
Hot dip galvanized
Galfan coated (Zinc-5%Al Aluminum) (Zinc-10%Al Aluminum)
PVC coated
BZ-08 1x0.5x0.3m 3.0-10.0mm Square mesh: 50x50 75x75 100x100 150x150
Rectangle mesh: 30X50 30X80 50X80 50X100 100X150 100X200		 Electro galvanized
Hot dip galvanized
Galfan coated (Zinc-5%Al Aluminum) (Zinc-10%Al Aluminum)
PVC coated
BZ-09 1x0.3x0.3m 3.0-10.0mm Square mesh: 50x50 75x75 100x100 150x150
Rectangle mesh: 30X50 30X80 50X80 50X100 100X150 100X200		 Electro galvanized
Hot dip galvanized
Galfan coated (Zinc-5%Al Aluminum) (Zinc-10%Al Aluminum)
PVC coated
Note: All sizes can be customized according to your request.
Our Gabion box is made from strengthened hot dipped galvanized or zinc-aluminium coated steel which delivers exceptional corrosion resistance.
Welding Procedure
  • Galvanized After Welding: welding first and then galvanizing, the surface of the welded mesh panel is more flat and beautiful.
  • Galvanized Before Welding: galvanizing first before welding, with obvious solder joints.
  • Firm Welding Spots: tightly welded steel wires form a stable grid panel that is not easily broken.
Gabion Box Advantages
Technology
Material: low carbon steel wire
Wire diameter: 3.0-6.0mm
Surface: passivation and plasticization of electro-galvanized, hot-dip galvanized, plastic coated, dip-coated or Galfan
Color: silver, green, etc.
The wire used to manufacture double twisted gabion wire mesh is soft annealed, mild steel wire provided with heavy zinc coating as per EN 10244/ASTM A 641 to prevent corrosion. In case of use in aggressive environments, it is further extruded with 0.5mm thick PVC Coating.
Features
  • Durable structure with greater strength
  • Better shape control
  • Utmost corrosion resistance
  • Easy to assemble
  • Aesthetically appearance
Welded Mesh Gabions are constructed using square electro welded weld mesh panels of high tensile steel. They are increasing in popularity due to their comparative ease and speed of installation. They are an economical environmental solution for structural retaining walls and coastal defences.
Product Applications
  • Protection Mesh: river bank protection gabion, gabion retaining wall, soil protection gabion, road isolation and protection gabion, slope protection gabion fence, gabion flood control retaining wall, etc.
  • Building Applications: gabion fence and gate, gabion building external wall, garden gabion, landscape gabion, animal gabion fence, poultry gabion cage, etc.
  • Decoration: flower bed gabion, gabion bench, lawn gabion, gabion sculpture, lampshades, gabion stools, gabion fire pits, etc.
Company Profile
Anping Bingze Wire Mesh Products Co., Ltd. has focused on the production and research and development of stainless steel wire mesh for 25 years. It is a manufacturer integrating production, processing, distribution and wholesale. The main products include galvanized welded wire mesh, stainless steel welded wire mesh, PVC welded wire mesh, crimped wire mesh, galvanized woven wire mesh, stainless steel woven wire mesh, chain link fence, steel fence, welded wire mesh fence panels, PVC euro fence, 358 anti-climb fence, razor wire, Hesco Barrier, Gabion Box and so on.
Since its beginning, we have been working at four points: High Quality, Quick Delivery, Better Price and Thorough Service. Rely on the product quality and our credit standing, we have got favourable comments from the customers. The company introduces precise making machines and technics, combining scientific inner managing method and quality control system.
Since the year it was established, we developed our powder and credit standing and got reliances of our customers in home and abroad. Our products is checking by very high standard, and the qualified ones leaved the factory to the whole county and some abroad countries, such as Southeast Asia, Middle East, America, Japan, and some Africa countries.
Certifications
Galfan Coated Gabion Box with Hot Dip Galvanized Wire Mesh and 450 N/mm2 Tensile Strength for Stone Retention
Frequently Asked Questions
Q1: Are you trading company or manufacturer?
A1: We are manufacturer.
Q2: Do you have your own R&D team?
A2: Yes, we can customize products as your requirements.
Q3: How about the quality?
A3: We have the best professional engineer and strict QA and QC system.
Q4: Can we be your distributor?
A4: We are looking for distributor and agent all over the world.
Q5: How's the package?
A5: Normally are Tray, but also we can pack it according to your requirements.
Q6: How's the delivery time?
A6: It depends on the quantity you need, 1-25 days usually.
