304 Stainless Steel Woven Wire Mesh Crimped 100 Mesh Roll
304 Stainless Steel Woven Wire Mesh Crimped 100 Mesh Roll
304 Stainless Steel Woven Wire Mesh Crimped 100 Mesh Roll
304 Stainless Steel Woven Wire Mesh Crimped 100 Mesh Roll
304 Stainless Steel Woven Wire Mesh Crimped 100 Mesh Roll
304 Stainless Steel Woven Wire Mesh Crimped 100 Mesh Roll
304 Stainless Steel Woven Wire Mesh Crimped 100 Mesh Roll
304 Stainless Steel Woven Wire Mesh Crimped 100 Mesh Roll
Specifications
Brand Name :
Vinstar
Place of Origin :
Anping,China
MOQ :
10 square meter
Price :
negotiated
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability :
30000-50000m2/month
Delivery Time :
7-30 days
Packaging Details :
Kraft paper and weaving bags,or tray
name :
304 Stainless Steel Woven Wire Mesh Crimped 100 Mesh Roll
Material :
304
Wire Dia. :
0.025-3.0mm
Mesh :
1-635 mesh
Weaving :
Plain,Twilled and Dutch Weaving
Width :
0.5-3.0m
Type :
Weave Wire Mesh
Technique :
Woven
Application :
Filter
hole shape :
square
Description

304 stainless steel Woven crimped wire mesh 100 mesh stainless steel wire mesh roll

Material: Stainless steel wire 302,201,304,304L,316,316L,310,310S etc.

Weaving Type: Plain Weave, Twilled weave, and Dutch Weave.

Characteristics: Acid-resisting, alkali-resisting, heat-resisting and wear-resisting.

Applications:

Stainless steel woven mesh is often used in the following applications:

Architectural mesh

Filtration

Fly Screen/Security Mesh

Bushfire Protection

Mesh/Inch Wire Diameter Aperture Open Area Weight(LB) /100 Square Foot
Inch MM Inch MM
1x1 .080 2.03 .920 23.37 84.6 41.1
2X2 .063 1.60 .437 11.10 76.4 51.2
3X3 .054 1.37 .279 7.09 70.1 56.7
4X4 .063 1.60 .187 4.75 56.0 104.8
4X4 .047 1.19 .203 5.16 65.9 57.6
5X5 .041 1.04 .159 4.04 63.2 54.9
6X6 .035 .89 .132 3.35 62.7 48.1
8X8 .028 .71 .097 2.46 60.2 41.1
10X10 .025 .64 .075 1.91 56.3 41.2
10X10 .020 .51 .080 2.03 64.0 26.1
12X12 .023 .584 .060 1.52 51.8 42.2
12X12 .020 .508 .063 1.60 57.2 31.6
14X14 .023 .584 .048 1.22 45.2 49.8
14X14 .020 .508 .051 1.30 51.0 37.2
16X16 .018 .457 .0445 1.13 50.7 34.5
18X18 .017 .432 .0386 .98 48.3 34.8
20X20 .020 .508 .0300 .76 36.0 55.2
20X20 .016 .406 .0340 .86 46.2 34.4
24X24 .014 .356 .0277 .70 44.2 31.8
30X30 .013 .330 .0203 .52 37.1 34.8
30X30 .012 .305 .0213 .54 40.8 29.4
30X30 .009 .229 .0243 .62 53.1 16.1
35X35 .011 .279 .0176 .45 37.9 29.0
40X40 .010 .254 .0150 .38 36.0 27.6
50X50 .009 .229 .0110 .28 30.3 28.4
50X50 .008 .203 .0120 .31 36.0 22.1
60X60 .0075 .191 .0092 .23 30.5 23.7
60X60 .007 .178 .0097 .25 33.9 20.4
70X70 .0065 .165 .0078 .20 29.8 20.8
80X80 .0065 .165 .0060 .15 23.0 23.2
80X80 .0055 .140 .0070 .18 31.4 16.9
90X90 .005 .127 .0061 .16 30.1 15.8
100X100 .0045 .114 .0055 .14 30.3 14.2
100X100 .004 .102 .0060 .15 36.0 11.0
100X100 .0035 .089 .0065 .17 42.3 8.3
110X110 .0040 .1016 .0051 .1295 30.7 12.4
120X120 .0037 .0940 .0064 .1168 30.7 11.6
150X150 .0026 .0660 .0041 .1041 37.4 7.1
160X160 .0025 .0635 .0038 .0965 36.4 5.94
180X180 .0023 .0584 .0033 .0838 34.7 6.7
200X200 .0021 .0533 .0029 .0737 33.6 6.2
250X250 .0016 .0406 .0024 .0610 36.0 4.4
270X270 .0016 .0406 .0021 .0533 32.2 4.7
300X300 .0051 .0381 .0018 .0457 29.7 3.04
325X325 .0014 .0356 .0017 .0432 30.0 4.40
400X400 .0010 .0254 .0015 .370 36.0 3.3
500X500 .0010 .0254 .0010 .0254 25.0 3.8
635X635 .0008 .0203 .0008 .0203 25.0 2.63

304 Stainless Steel Woven Wire Mesh Crimped 100 Mesh Roll304 Stainless Steel Woven Wire Mesh Crimped 100 Mesh Roll
