Specifications
Brand Name :
HONGBAO
Model Number :
HG-OP
Certification :
PED, ISO9001,DNV
Place of Origin :
China
MOQ :
1MT
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
3000MT/Month
Delivery Time :
Negotiable
Packaging Details :
As required
Steel Grade :
30CrMo, 42CrMo, 30CrMnSiA, 40Mn2, 45MnMoB, 30CrMnSiA, 4135, 1541
Execution Standard :
ASTM A519, DIN2391, EN10305-1, GB/T 9808
OD Range :
30-139.7mm
WT Range :
3-19mm
Processing :
Cold Roll, Cold Drawn
Color :
Black
Description

4140(42CrMo/42CrMo4) Grade Drilling Pipe – High-Strength Solution for Demanding Oilfield Wells​​

​Engineered for high-pressure, high-load drilling environments​​, 4140 grade drilling pipe delivers ​​exceptional strength, superior wear resistance, and reliable performance​​ for the toughest oilfield applications.

​​Key Advantages​​

1. ​​Ultimate Strength​​ – Tensile strength ≥950 MPa, yield strength ≥850 MPa for ​​deep wells and high-pressure reservoirs​​ (far exceeding standard grades).

2. ​​Premium Hardness (28–33 HRC)​​ – Exceptional resistance to ​​abrasion and wear​​ from drill cuttings and hard formations, extending service life.

3. ​​Quenched & Tempered (QT) Process​​ – Delivers ​​balanced strength and toughness​​, preventing brittle failure under extreme loads.

4. ​​High-Cost Performance​​ – Chromium-molybdenum (Cr-Mo) alloying provides ​​superior fatigue resistance and high-temperature stability​​ vs. standard carbon steels.

5. ​​Proven in Harsh Conditions​​ – Trusted for ​​ultra-deep wells, HPHT wells, and abrasive formations​​ where ordinary pipes fail.

​​Ideal for:​​ Deep drilling, high-pressure reservoirs, hard rock formations, and heavy-duty operations.

​​Upgrade from 4130/1541 when extreme strength and wear resistance are required.​

Applications include fore poling (advance support), mine blasting, water well drilling, geothermal well drilling, and coal/nonferrous metal mining.​​

Chemical Composition

Steel Grade C Si Mn P S Cr Mo B

4130

 0.28-0.33 0.15-0.35 0.40-0.60 ≤0.040 ≤0.040 0.80-1.10 0.15-0.25
4140 0.38-0.43 0.15-0.35 0.75-1.00 ≤0.040 ≤0.040 0.80-1.10 0.15-0.25
45MnMoB 0.43-0.48 0.17-0.37 1.05-1.35 ≤0.020 ≤0.015 0.20-0.25 0.001-0.005

1541

 0.36-0.44 - 1.35-1.65 ≤0.040 ≤0.050

30CrMnSiA

 0.28-0.34 0.90-1.20 0.80-1.10 ≤0.020 ≤0.015 0.80-1.10

Mechanical Properties

Steel Grade

 Deliver Condition Tensile Strength(Mpa) Yield Strength(Mpa) Elongation(%) Hardness(HRC)
4130 + SR ≥813 ≥690 ≥15% ≥24
4140 QT ≥950 ≥850 ≥14% 28 - 33
45MnMoB + N ≥790 ≥600 ≥14% -
1541 + SR ≥813 ≥690 ≥15% ≥24
30CrMnSiA QT ≥850 ≥750 ≥14% 26 - 31

Delivery Condition:

1. Stress Relief Annealing after Cold Working (+SR) (BKS)

2. Normalizing (+N) (NBK)

3. Quenching & Tempering (QT)

ASTM A513 A519 Drill Rod Oil Drilling Pipe 42CrMo4 Steel Outer Tube with Excellent microstructure

FAQ:

1. Can you provide a sample to check the quality?
We can provide free sample with same or similar sizes for you to check tube quality.
You need to in charge of Express costs.

2. How about your production capacity?
3000 tons/Month.

3. What are your terms of payment?
30%TT in advance, Balance to be paid before shipment.

4. Where is your factory?
Zhangjiagang city, 1.5 hours away from Shanghai.

5. How can I get the quotation A.S.A.P?
Please send us an inquiry with full details as following,quotation will sent to you A.S.A.P:
1). Tube Standard
2). Steel Grade
3). Tube Size and Size Tolerance
4). Tube length
5). Quantity
6). If any special requirements

6. How about the minimum order quantity?
Normally for one size above 1 ton.
