Specifications
Place of Origin :
Guangdong, China
Condition :
New
Type :
Hydraulic Cutting Machine
Brand Name :
WEIZHEN
Voltage :
AC380V
Power :
5500
Warranty :
1 Year
Applicable Industries :
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising C
Rated Power :
5500W
Max. Cutting Depth :
100 mm
Dimensions :
2300*1500*1500mm
After-sales Service Provided :
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support
Certification :
CE
Cutting force :
60T
Stroke :
250mm
Cutting thickness :
100mm
Cutting area :
1400*800mm
Packaging Details :
Wooden case
Port :
HUANGPU
Supply Ability :
300 Set/Sets per Month
Price :
$7,500.00/sets >=1 sets
MOQ :
1 set
Description

Precise 4-column hydraulic cutting machine

Application :

The machine is mainly suitable for cutting materials needed cutting out like all kinds of EPE and synthetic materials.

Features :

l Easy-handle,low failure rate,fast Cutting

l Dual cylinders and precise 4-column automatic equilibrium joint structure,which can guarantee the same cutting depth of each cutting position.

l Knife mould setting device, Which can perform high/low knife mould adjustment at ease,in accuracy

l and promptness.

l Automatic slow cutting when the cutting board presses downward and touches the knife.ensuring no size error between the top and bottom layers of cutting materials.

l Centralized lubricating system guarantees the precision of the machine and makes the machine durable.

Specification :

Model

Cutting Force

Stroke

Motor power(kw)

Cutting Area(L*W,mm)

Dimension(L*W*H)(mm)

NM(kg)

WZ-4012

40

50-250

3

1200*600

1900*1200*1500

1900

WZ-4016

40

50-250

3

1600*600

2400*1200*1500

2300

WZ-6012

60

50-250

4

1200*700

2100*1300*1500

2400

WZ-6016

60

50-250

4

1600*700

2450*1300*1500

3100

WZ-8012

80

50-250

5.5

1200*800

2200*1400*1500

3800

WZ-8016

80

50-250

5.5

1600*800

2580*1400*1500

4200

WZ-10012

100

50-250

7.5

1200*900

2300*1500*1500

4500

WZ-10016

100

50-250

7.5

1600*900

2680*1500*1500

5400
