Jichai Shengdong 12V190 Engine Parts List

• Spark plug cap — 1812T.03.05

• O-ring — 37.5×3.55 G GB/T3452.1

• Piston ring — 12VB.05.09C-GJ

• Piston — W12V190.05.01

• Piston pin — 12V.05.08A

• Small end bushing — 12VB.05.10.08

• Connecting rod nut — 12VB.05.10.09

• Washer — 12VB.05.10.06

• Connecting rod bolt — 12VB.05.10.03

• Connecting rod bearing — 12VB.05.10.04A/05A

• Roller rocker arm assembly — Z12VB.06.10.00

• Camshaft assembly — 10W12V190.06.10/PJ

•

Exhaust pipe:

• 10W12V190.09.13A

• 10W12V190.09.16A

• 10W12V190.09.18A

• 10W12V190.09.12A

• 10W12V190.09.15A

• 10W12V190.09.17A

Exhaust pipe insulation layer:

• 10W12V190.09.60.20

• 10W12V190.09.60.10

• 10W12V190.09.60.30

• 10W12V190.09.60.40

• 10W12V190.09.60.60

• Gasket — 51×82 Q/SDL14006-2003

• Water pump — 10W12V190.22.00B

• Spark plug — 1.0301E+11

• Flange butterfly valve — D341X5-10/16ZB1

• Valve retainer (lock) — 12V.03.16A

• Rocker arm assembly — 127.03.100

• Exhaust pipe gasket — Z12VB.09.40

• Tappet — Z12VB.06.20A

• Intake pipe gasket — 12VB.08.10.14

• Cylinder head gasket — 206L.01.31

• Crankshaft oil seal — PG160×130×15

• Water pump gasket — 12VB.01.82

• Gasket (sight glass gasket) — 12VB.01.146C-1

• Pipe — 12V.01.09

• Bushing — 12VB.01.05

• Return pipe — 12VB.24.07

• Sealing ring — 12V.01.12

• Camshaft bearing — 12VB.01.34

• Free shaft bushing — 12VB.01.43

• Intermediate end bushing — 12VB.01.42

• Flywheel end bushing — 12VB.01.41A

• Valve stem oil seal — 127.03.80.06

• Inner spring — Z12.03.17A

• Outer spring — Z12.03.18A

• Retaining ring — GB/T893.125

• Retaining ring — 12VB.03.52

• Cross bridge module assembly — 127.03.03C

• Nut — 127.03.15

• Upper cover rubber ring — 12VB.03.13A

• Lower cover rubber ring — 12VB.03.12A

• Nuts, springs, flat washers — 10

• Refractory bolts — 235.09.07

• Stud bolt — GB898-10×35

• Oil-through screw — 8Q

• Gasket — 14009-8

• Gasket — 10W12V190.15.02A

• Gasket — 10W12V190.09.19

Product Offerings

Jinan Diesel Engine: Jichai 190 series, 6190, 8190, 12V190, 16V190 diesel and gas engine.

Shengdong Gas Generator: 500kW, 700kW gas generators.

Weichai Engines: 6170Z, 8170Z, CW6200, CW8200, R6160Z, WP12, and WP series.

Weichai Baudouin Series: 6M26, 6M33, 12M26, 12M33, 16M33, 12M55, M26, M33, M55 Series.

Zichai Engines: Z6170, Z8170, 6210, 8210, LB8250, LC8250, ZC6200, Z6180, Z8180, Z6150, 6300, 8300.

Generator Sets: (20-2000KW) from leading domestic brands such as Jichai, Shengdong, Zichai, and Yuchai.​

Commitment to Excellence

Shandong Hongfan Power Technology Co., Ltd. is committed to delivering high-quality products and reliable services with integrity and innovation. The company has earned widespread acclaim and loyalty from customers through continuous improvement and exceptional service.
