Silver Stainless Steel 316L 40 Inch Woven Wire Panels Industrial
Silver Stainless Steel 316L 40 Inch Woven Wire Panels Industrial
Silver Stainless Steel 316L 40 Inch Woven Wire Panels Industrial
Silver Stainless Steel 316L 40 Inch Woven Wire Panels Industrial
Silver Stainless Steel 316L 40 Inch Woven Wire Panels Industrial
Silver Stainless Steel 316L 40 Inch Woven Wire Panels Industrial
Specifications
Brand Name :
STD
Model Number :
STD-WWM-010
Certification :
FDA ,CE，ISO9001
Place of Origin :
Hebei,CN
MOQ :
1
Price :
To be negotiated
Payment Terms :
L/C, T/T, Western Union,
Supply Ability :
200 pieces per day
Delivery Time :
5-8word days
Packaging Details :
carton inside and wooden box outside.
Name :
Woven Wire Mesh
Material :
304 stainless steel
Color :
Silver
Size :
Customizable
Specification :
5, 10, 20, 30, 40 inch
Application :
Industrial filtration
Applicable :
Manufacturing Plant, Construction works
Type :
Net
Hole Shape :
Square
Thickness :
Customers' Request
Width :
Customers' Request
Technique :
Woven
Description

Stainless Steel Woven Wire Mesh Metal Mesh Screen For Industrial

product description:

The Woven Metal Mesh Screen includes two kinds:Wire Screen and Mesh Sieve

Wire screen or a mesh sieve is a common application of wire mesh. Both type of products have the same goal, which is to prevent objects or creatures gaining access. However, as logical as it seems, these wire meshes need to have the correct specifications in order to fulfill their tasks in the long term.

Wire screen

Wire mesh screens can be used to keep out unwanted things like insects. But they can also be used for netting purposes to protect human beings from falling masonry from old buildings or from rock falls.

Another application of a wire screen is to use it as a radiation shield, against radio signals for instance. It can also be utilized for a faraday cage to create an enclosure which blocks external electric fields.

Mesh sieve

Another application of wire mesh is to use it for sieving purposes. Mesh sieves are used for instance within the chemical and mining industries. The chemical industry utilizes wire mesh sieves for sieving unwanted particles out of chemicals which cause pollution in the product. The mining industry uses wire mesh sieves to separate small rocks from big rocks within their process, this is mostly done by wire mesh which is very robust with a large mesh.

Product Name
Woven Wire Mesh, Wire Cloth
Stainless Steel Grade
304, 316, 316L, etc
Special Material Options
Inconel,, Nickel, Titanium, etc
Wire Diameter Range
0.02 - 6.30mm
Hole Size Range
1 - 3500mesh
Weave Types
Plain Weave
Twill Weave
Dutch or 'Hollander' Weave
Plain Dutch Weave
Twill Dutch Weave
Reverse Dutch Weave
Multiplex Weave
Mesh Width
Standard less than 2000 mm
Mesh Length
30m rolls or cut to length, minimum 2m
Mesh Type
Rolls and sheets are available
Production Standards
ASTM E2016 - 20
Certification
ISO9001: 2015

Others Application

  • Protective grilles, screens and barriers
  • Security screens and partitions
  • Sunscreens stair railings
  • Suspended walkway railing
  • Infill panels
  • Parking structures
  • Elevator compartments and hoistways
  • Protective enclosures
  • Trellises

Silver Stainless Steel 316L 40 Inch Woven Wire Panels Industrial

Silver Stainless Steel 316L 40 Inch Woven Wire Panels Industrial

The Package and Delivery

Silver Stainless Steel 316L 40 Inch Woven Wire Panels Industrial

Silver Stainless Steel 316L 40 Inch Woven Wire Panels Industrial
