60m Dia Large Outdoor Exhibition Tents For Temporary Event , Competition
60m Dia Large Outdoor Exhibition Tents For Temporary Event , Competition
60m Dia Large Outdoor Exhibition Tents For Temporary Event , Competition
60m Dia Large Outdoor Exhibition Tents For Temporary Event , Competition
60m Dia Large Outdoor Exhibition Tents For Temporary Event , Competition
60m Dia Large Outdoor Exhibition Tents For Temporary Event , Competition
Specifications
Brand Name :
LIRI TENT
Model Number :
TH 40m / 400
Certification :
ISO9001:2008, SGS, TUV, CFM, IFAI, etc.
Place of Origin :
CHINA( Mainland), Guangdong
MOQ :
1 set
Price :
negotiable
Payment Terms :
Western Union, L/C, T/T
Supply Ability :
100,000sqm/month
Delivery Time :
within 20 days
Packaging Details :
1 . membrane film. 2. Carton . 3. PVC carry bag .
Function :
Exhibition
Roof Fixing :
Tensioning Bar
Side Walls :
PVC sidewalls
Ground Situation :
grass land, concrete ground, and more
Accessories :
Glass walls, flooring system , roof lining
Life Span :
20 years for frame, 10 years for fabric
Color Option :
black, , white , green , transparent , red
Description

60m Dia Temporary Large Outdoor Exhibition Tents For Temporary Event , Competition


Applications:

It is widely use for the exhibitions, brand launches, theater, concert party, and other large -scale activities. Different color and transparent cover are available, what's more, inkjet and CNC sculpture can be used to make a custom unique fabric, providing a satisfactory solution for each customer.

Dimension Diameter Ceiling Height Floor Area Vloume
Dia 40 40m 15m 1256m² 11191m³
Dia 50 50m 20m 1962.5m² 23823m³
Dia 60 60m 25m 2826² 43524m³
Length No limitation
Main Structure Profile 300*120*5m


Description:

The big tent series size from 25-40 m , it can use for different kinds of events , warehouse , and more. This series of tent can fix with full line accessories .

60m Dia Large Outdoor Exhibition Tents For Temporary Event , Competition

Tent Fixing Methods
  • If it is concrete ground , pls use the expandable bolts
  • If it is termac grond or grass ground or sand ground or other soft gronds , pls use the steel anchors .
  • If it is marble or tile ground or other kind indestructible grounds , pls use the weight plates system
  • If you will make the concrete bases to fix the tent , pls use the embeded bolts M 24 x 500 mm

Optional Accessories

  • Windows: dome or square clear PVC windows, mesh window, glass window for glass wall
  • Wooden Flooring System: VIP cassette flooring, simple cassette flooring
  • Doors: double-wing glass door, single-wing glass door, glass fire door, aluminium door, rolling shutter(automatic or manual)
  • Wall: soft PVC fabric wall, glass wall, ABS hard wall, sandwich panel wall, steel plate wall
  • Fixing Methods: ground anchors, weight plate, expandable bolts
  • Rain Gutters:inner roof beam rain gutter or rain gutter between two similar tents
  • Other Optional Items: table, chair, lighting, AC, carpet, installation tools etc.
  • Adjustable flooring system, can fix on the uneven land

Structure


Framework: hard pressed extruded aluminum 6061/T6(15HW) which can last more than 20 years.
Fabric Cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.
Connector: strong hot-dip galvanized steel
Allowed Temperature Condition: -30 degree Celsius~+70 degree Celsius
Wind Loading: max. 100km/h (can be reinforced)
Snow Loading: 30kg/sqm (snow can't stay if use big degree roof pitch design)
Easy to be assembled and dismantled, movable.
No pole inside, 100% available interior space.

Superiority of tents

1 Sizes can be customized
2 Allowed temperature condition: -30 degree Celsius~+70 degree Celsius
3 No pole inside, 100% room is available
4 Trouble-free and easy transportation, erection, dismantling, storage
5 Wind loading up from 80 to 100 km per hour
6 Multifunctional, widely used for different request

Life Span:

For the structure of the tent, it is strong enough for permanent or semi - permanent. The frame is using the 6061/ T6 aluminum frame, and it can use for about 20-25 years. If for the pvc roof cover, it can use for about 8 - 10 years.
