JUKI Pick and place machine RX-6B

Product feature:

Juki's already reliable technology has evolved to an all new level! The compact RX-6R/RX-6B offers high productivity, flexibility and quality - in a compact footprint.

Compact Footprint: the width is just 1.25 m

1. New head design results in increased placement speed from previous model.

2. Replaceable heads allow you to configure a production line best suited to the current requirements.

Equipment parameter:

• This is applicable to dual-lane production.*6

  Compact footprint : the width is just 1.25m

  Equipped with standard Placement Monitor check function.*1

  Replaceable head allow you to configure a production line best suited to the current repirments.*6

  High-speed component placement using high-speed non-stop vision recognition.*3

  Wide range of components and boards: tall components, large components and large boards.

  Brand new Matrix Tray Sever TR8S improves the component capability and productivity.

  High-Speed Compact Modular Mounter RX-6B (6×6 nozzle head)
  Board size	Single lane conveyor		50×50 ~ 610×590 / 905×590mm (2times clamping)
  	Dual lane conveyor		50×50 ~ 360×250mm*1
  Component height			6 / 12 / 20 / 25 / 33mm
  Component size	Component size		0402 ~ 33.5mm×33.5mm
  	Vision recognition*2	Standard camera	3mm×3mm ~ 100mm×100mm / 50×180mm
  		High-resolution camera	1005 ~ 48mm×48mm / 24mm×72mm
  Placement speed	Chip	Option*3	34,000CPH
  		IPC9850	23,000CPH
  	IC*4		11,000CPH
  Placement accuracy	Laser recognition		±0.04mm(Cpk≧1)
  	Vision recognition*2		±0.03mm
  Placement loading quantity			Max.160 in case of 8mm tape (on a Electric double tape feeder)



• FAQ

  Q: What we can do for you?
  A: Total SMT Machines and Solution, professional Technical Support and Service.
  Q:Are you a trade company or a manufacturer?
  A: OEM & ODM service are available.
  Q: What is your delivery date?
  A: The delivery date is about 35 days after receipt of payment.
  Q: What is your payment terms?
  A: 30% deposit in advance and 70% balance before shipment.
  Q: Why choose us?
  A: Leading SMT Supplier in China; Professional after-sales service team.
