ODM Continuous Ambient Air Pollution Monitoring Instruments AQ7800
ODM Continuous Ambient Air Pollution Monitoring Instruments AQ7800
Specifications
Brand Name :
Wayeal
Model Number :
AQ7800
Certification :
ISO, CE
Place of Origin :
Anhui, China
MOQ :
1
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
20 Pieces Per Month
Delivery Time :
15 days
Packaging Details :
One piece per wooden case
Product Name :
Ambient Air Quality Monitoring Instruments
Repeatability :
≤±5%
Linearity error :
≤±1% F.S.
Measurement Method :
GC-FID
Analysis cycle :
≤15min
Detector :
FID
Description

Continuous Ambient Air Quality Monitoring Instruments of Total Non-methane Hydrocarbons

Product Introduction

The AQ7800 automatic ambient air quality non-methane monitoring system monitors methane, non-methane total hydrocarbons and the five meteorological parameters (temperature, humidity, pressure, wind speed, wind direction) and other related parameters.

Product Parameter

Product Name Ambient Air Quality Monitoring Instruments
Size 1030*720*2060mm, 970*900*1000mm
Working Temperature 15-35C°
Measurement Range 0-5ppm
Measurement Error ≤±1% F.S.
Measurement Method GC-FID
Detection Limit ≤20 ppb
Working Humidity ≤85%RH
Linearity error ≤±1% F.S.
Repeatability ≤±5%

Product Performance

1. Accurate and stable pressure and flow control, with a pressure control accuracy better than ±0.05kPa and a flow control accuracy better than 0.5% F.S.
2. Column box control accuracy is better than ±0.1℃.
3. Adopt imported valve, low maintenance and long service life.
4. The use of a miniature FID detector, more sensitive response to methane and non-methane total hydrocarbons.

Industry Application

Mainly for ambient air monitoring of methane and non-methane total hydrocarbons;
Ambient air monitoring, Atmospheric monitoring of plant boundaries in chemical parks
