1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
Specifications
Brand Name :
Wayeal
Model Number :
SFJ-231
Place of Origin :
Anhui, China
Certification :
CE
MOQ :
1 Unit
Price :
Negotiate
Packaging Details :
Wooden Case
Delivery Time :
35 days
Payment Terms :
T/T, VISA
Supply Ability :
200 Units/Month
Operating temperature :
0~40°C
Start Time (min) :
≤2
Language :
Chines/English
Response Time(s) :
<1
I/O Input output interface :
8 Inputs, 8 Outputs
Communication Interface :
RS232/485, USB*2
Product Name :
Helium Leak Detector
Diamension :
645*678*965mm
Description

1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection

Introduction of Helium Leak Detector:

Helium leak detector is an advanced vacuum leak detection device designed for industrial leak testing applications. It features a high-precision mass spectrometer leak detector, providing a mini leak detection rate of 5*10-9 Pa·m3/s in sniffer mode, and a fast start time of ≤2 minutes. The intuitive user interface of the device is a 7inch color touch screen, which displays the leak rate in numbers, bar charts and graphs, making it easier to analyze the data. The operating temperature range is 0~40°C, making it suitable for a wide range of industrial environments. With its precision and accuracy, this helium leak detector is an ideal choice for industrial vacuum detection

Technical Parameters of Helium Leak Detector:

Helium Mass Spectrometer Leak Detector for Pouch Cell Leak Detection
Product Name Helium Leak Detector
Diamension 645*678*965mm
Operating temperature 0~40°C
Detectable Quality 2, 3, 4 (H2, He3, He4)
User Interface 7inch Color Touch Screen
Detection Method Helium Leak Detection
Mini Leak Detection Rate(Pa.m3/s)/Vaccum Mode 5*10-13 Pa·m3/s
Communication Interface RS232/485, USB*2
Max Allowable Leak Detection Pressure (Pa) 1500
Ion Source 2pcs, Iridium Coated Yttrium Oxide, Automatic Switching
Main Features Mass Spectrometer Leak Detector, Helium mass spectrometer Leak Detector, helium leak testing
Mini Leak Detection Rate(Pa.m3/s)/Sniffer Mode 5*10-9 Pa·m3/s
Start Time 2min
Leak Detection Port DN25KF
Power AC220V, 50Hz/60Hz
Language Chinese/English

Support and Services:

Helium Leak Detector Technical Support and Service

We are dedicated to providing the highest quality technical support and service for our Helium Leak Detector products. We could provide you witn on-site service calls, remote diagnostic and repair services, and telephone support. Our technicians can also provide preventative maintenance and calibration services to ensure your Helium Leak Detector is functioning optimally.

Methods of Leak Detection

Negative Pressure Method

1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection

Vacuum Chamber Helium Leak Detection and Recovery System (external filling)

1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection

Sniffer Method

1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection

1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection

1500Pa Helium Mass Spectrometer Leak Detector For Pouch Cell Leak Detection
