Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine
Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine
Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine
Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine
Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine
Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine
Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine
Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine
Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine
Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine
Specifications
Brand Name :
Wayeal
Model Number :
SFJ-16D
Certification :
CE
Place of Origin :
Anhui, China
MOQ :
1 Unit
Price :
Negotiate
Payment Terms :
T/T, VISA
Supply Ability :
200 Units/Month
Delivery Time :
35 days
Packaging Details :
Wooden Case
Ion Source :
2pcs, Iridium Coated Yttrium Oxide, Automatic Switching
Leak rate display :
Numbers, Bar Charts, Graphs
Start Time (min) :
≤1.58min
Response Time(s) :
<1s
Diamension :
475 * 714 *1168mm
I/O Input output interface :
8 Inputs, 8 Outputs
Detection Method :
Helium Mass Spectrometer
Mini Leak Detection Rate(Pa.m3/s)/Sniffer Mode :
2.5*10-9 Pa·m3/s
Description

Introduction of Helium Leak Detector:

Helium leak testing is essential to guarantee the system or equipment is leak-free when employing a high-pressure or vacuum system. Helium leak detection is the most effective method for detecting leaks since helium is one of the lightest and tiniest molecules and will find its way out of even the smallest openings. Thus, the helium leak detector is an indispensable asset for maintenance professionals and engineers in various fields including aerospace, automotive, refrigeration, and semiconductor manufacturing.

Technical Parameters of Helium Leak Detector:

Helium Leak Detector With Mass Spectrometer Iridium Coated Ion Source Sensitivity

Product Name

Helium Leak Detector
Detection Method Helium Mass Spectrometer
Leak Detection Port DN25KF
Leak Rate Display Numbers, Bar Charts, Graphs
Response Time(s) <1s
User Interface 7inch Color Touch Screen
Operating temperature 0~40°C
Max Allowable Leak Detection Pressure (Pa) 1800
Communication Interface RS232/485, LAN
Detectable Quality 2, 3, 4 (H2, He-3, He-4)
Mini Leak Detection Rate(Pa·m3/s)/Sniffer Mode 5.0*10 -13 Pa·m3/s
Mini Leak Detection Rate(Pa·m3/s)/Vacuum Mode 2.5*10-9 Pa·m3/s
Startup Time (min) ≤1.58
Backing Pump Scroll Vacuum Pump
Diamension 475*714*1168mm
Power Supply AC220V, 50Hz/60Hz
Language Chinese/English

Applications of Helium Leak Detector:

Helium leak detectors are widely used in various industries to detect and locate small leaks. The most common applications of helium leak detectors include:

Semiconductor manufacturing, aerospace, and research facilities;

Refrigeration and air conditioning systems. They are used to locate leaks in compressors, condensers, evaporators, and other components of the system.

Automotive industry: Helium leak detectors are used to test the fuel tanks, radiators.

Methods of Helium Leak Detection (Helium Leak Detector)

Helium Vacuum Method

Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector MachineHelium Hood Method

Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine

Negative Pressure Method

Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine

Vacuum Chamber Helium Leak Detection and Recovery System (external filling)

Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine

Sniffer Method

Helium Leak Detection Equipment Iridium Coated Ion Source Helium Leak Detector Machine
