Technical parameters | Specifications | Technical parameters | Specifications |
Weight(kg) | 7500 | Drilling Depth(m) | 350 |
Drill Diameter(mm) | 105-350 | Lifting force(T) | 16 |
FastLifting Speeding(m/min) | 30 | Fast Feeding Speed | 55 |
Rotary Torque(N.m) | 8500/4250 | Uphillangle(°) | 21 |
PenetrationEfficiency(m/h) | 10-35 | Rotary Speed(r/min) | 80/160 |
Air consumption(m³/min) | 16-55 | Air Pressure(Mpa) | 1.2-3.5 |
Engine | Yuchai | Dimension(m) | 5.78*1.7*2.25 |
Winch lifting force(T) | 1.1/2.5(Optional) | Host power(kw) | 91 |
Drill pipe length(m) | 3/6 | Leg Stroke(m) | 1.5 |
Moving Speed(km/h) | 2.5 | Drill pipe diameter(mm) | 89/102 |
| | | |
Working condition | Unconsolidated formation and stone head | Drilling method | Topdrive hydraulic rotary and pushing hammer or mud diling |
Matched DTH hammer | Medium and high air pressure series | | |
Package Size | 578mm*170mm*225mm |
Package Gross Weight | 7500kg |
