300m Crawler Hydraulic Rock Drilling Machine With High Performance
300m Crawler Hydraulic Rock Drilling Machine With High Performance
300m Crawler Hydraulic Rock Drilling Machine With High Performance
300m Crawler Hydraulic Rock Drilling Machine With High Performance
Specifications
Brand Name :
ShiTan
Model Number :
ST-300
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1set
Price :
USD5000
Payment Terms :
L/C,T/T,D/A,Western Union,MoneyGram,Cash
Supply Ability :
500sets/year
Delivery Time :
15-25days
Packaging Details :
Plastic film and Standard export wooden box
Drilling depth :
300M
Drill rod diameter :
105-305MM
Maximum speed spindle :
1143r/min
High leg travel :
1.35m
Footage efficiency :
10-35m/h
Walking speed :
2.5km/h
Overall dimension :
4.8m×1.9m×2.35m
Engine :
Yuchai 78KW
Description
300m Crawler Hydraulic Rock Drilling Machine With High Performance
Product Description
Designed for industrial, civil, and geothermal drilling applications, this high-performance rig excels in large-diameter deep-hole operations. With drilling capabilities ranging from 105mm to 305mm diameters and depths up to 300 meters, it adapts to diverse geological conditions including loose formations and bedrock. Powered by a robust Yuchai 78kW engine for reliable operation.
Key Features
  • Compact structure with small footprint for easy transportation and site deployment
  • 30° gradeability for operation on challenging terrain and slopes
  • Versatile performance across loose layers, bedrock, and hard rock formations
  • Factory-direct pricing for cost efficiency
  • Professional technical support team available
  • Powered by reliable Yuchai 78KW diesel engine
Technical Specifications
Attribute Specification
Max. Drilling Depth 300 m
Hole Diameter Range 105 - 305 mm
Drilling Method Top Drive Hydraulic Rotation
Footage Efficiency 10 - 35 m/h
Max. Rotation Torque 8900 N.m
Max. Hoisting Force 22 T
Engine Power Yuchai 78 KW Diesel
Travel Speed 2.5 km/h
Gradeability 30 °
Operating Air Pressure 1.25 - 3.5 MPa
300m Crawler Hydraulic Rock Drilling Machine With High Performance 300m Crawler Hydraulic Rock Drilling Machine With High Performance 300m Crawler Hydraulic Rock Drilling Machine With High Performance 300m Crawler Hydraulic Rock Drilling Machine With High Performance
