XY-2 Four Wheel Trailer Drill Machine 300-600m Geological Exploration Drilling Well Diamond Core Drilling Rig
XY-2 Four Wheel Trailer Drill Machine 300-600m Geological Exploration Drilling Well Diamond Core Drilling Rig
Specifications
Brand Name :
JINZHOU SHITAN
Model Number :
ST-200
Certification :
ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
Negotiation
Delivery Time :
7-12 days
Packaging Details :
Standard Export Package
Condition :
New
Type :
Rotary Drilling Rig
Power Type :
Diesel
Usage :
Water Well
Voltage :
220V/380V, can be customized
Power(W) :
Diesel Power
Dimension(L*W*H) :
2500*1000*1300 mm
Description

XY-2 four wheel Trailer Drill Machine 300-600m Geological Exploration Drilling Well Diamond Core Drilling Rig

XY-2 four wheel trailer drill machine is mainly adapted to suit for engineering exploration, water well and foundation hole drilling, it can also be used in mineral exploration with diamond bit or tungsten-carbide tipped bit. Thie equipment is compact in structure, small in size, light in weight and convenient in transportation. It is with big spindle dia. which is cery suitable for engineering construction.

1.Unity Machine Parameter
Drilling Depth(m) 150~200m
Hole Diameter(mm) 75~200mm
Drill Rod Diameter 50
Drilling Angle 90~75
Drill Weight (No include power) 910kg
Overall Dimession 2750*950*1600mm
2.Spindle
Spindle Speed 64, 128, 287, 557r/min
Spindle Stroke 450mm
3.Hoist
Max. Single Line Hoisting Capacity 2000kg
Reel Lifting Speed 75, 151rm/s
Tightrope Diameter 13mm
Tightrope Cubic Measure 35mm
Hug Follgate Belt Width 70mm
Distance Between Drill and Hole 400mm

XY-2 Four Wheel Trailer Drill Machine 300-600m Geological Exploration Drilling Well Diamond Core Drilling Rig
