Specifications
warranty :
1 year, 1 year
customized support :
OEM
Place of Origin :
Hunan, China
Brand Name :
Changde
Model Number :
LXSG-15D~20D
type :
Multi-jet meters
Product name :
Single --jet Water Meter
Certificate :
ISO4064 ISO9001:2015
Material :
Brass
Type name :
Vane wheel single jet dry type cold water meter
Installation :
Horizontal
Water temperature :
≤30℃
Working pressure :
≤1.6MPa
Normal Size :
15mm~20mm
Description

Single-jet, vane wheel, dry-dial water meter

Dn15mm Dry Type of Sensus Water Meter with ISO 4064 Standard Water Meter

Product Features

--Single-jet, dry-dial, register with 5 or 8 numbered roller

--Magnetic drive, resistance to exterior magnet interference,

--Brass body can be painted or nickel coated;

--Pulse output for option.

Working condition(s)

Water temperature 0.1~30℃, 0.1~90℃ for hot water

Working pressure ≤1MPa. (1.6Mpa option) Pressure Loss ΔP63

Accuracy

Low region max. allowable error: From Q1 inclusive up to but excluding Q2 is ± 5%.

High region max. allowable error: From Q2 inclusive up to and including Q4 is ± 2%.

Hot water meter ±3%

Main technical parameters

Nominal Size

DN(mm)

Class of Measurement

Overload Flow-rate Q4(m3/h)

Permanent Flow-rate Q3(m3/h)

Transitional Flow-rate

Q2(l/h)

Minimum Flow-rate Q1(l/h)

15

B

3

1.5

120

30

20

B

5

2.5

200

50
