1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
Specifications
Place of Origin :
Zhejiang, China
Model Number :
2W-20SL
Brand Name :
Round Star
MOQ :
1
Price :
$8.99-12.99
Port size :
1"
Working medium :
water, liquid, air, light oil (viscosity≤20cst)
Medium temperature :
-5～80℃
Working pressure :
0～7 bar
Working type :
semi direct acting
Valve body material :
PA66 (from German)
Sealing material :
NBR (-5～80℃)
Interface :
G thread, NPT thread
Working voltage :
AC220～240V, AC110V 50/60Hz, DC24/12V
Power consumption :
DN15～25 AC20VA DC20W, DN32～50 AC50VA DC35W
IP rating :
IP65
Pilot pressure :
0.3～8 bar
Coil power :
AC25VA, DC13W
Energy saving :
AC220V 3VA, DC24V 3W
Thread type :
G thread, NPT thread
Description
Products Description
working medium：water、liquid、air、light oil（viscosity≤20cst）
medium temperature：-5 ～ 80℃
working pressure：0 ～ 7 bar
working type：semi direct acting
valvebody material：PA66(from German）
sealing material：NBR（-5 ～ 80℃）
interface：G thread NPT thread
working voltage：AC220～240V AC110V 50/60Hz DC24/12V
DN15～25 AC20VA DC20W DN32～50 AC 50VA DC35W
options： LED light connector
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty

YSA YSB-series 2-way pilot operated（NC）plastic solenoid valve 1/2＂～ 2＂

working medium：water、liquid、air medium temperature：-5 ～ 80℃
working pressure：0.3 ～ 8 bar working type：pilot operated, NC
valvebody material：PA66 sealing material：NBR
interface：G thread NPT thread
Working voltage：AC220～240V AC110V 50/60Hz DC24V YSA-series AC 25VA DC 13W IP65 H degree
Options: LED light connector Es low power energy saving coil（AC220V 3VA DC24V3W）
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
Certifications
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
Company Profile
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
Performance testing equipment for solenoid valve
To supply qualified products,each solenoid valve has been tested strictly.
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
Automatic digital winding machine for the production of coil
We useautomatic digital high-speed winding machine for the production of coil. The machine is characteristic of parallel winding,
high precision and high speed.
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
Coil plastic capsulation workshop corner

1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
Performance testing machine for solenoid coil
To guarantee the quality, each solenoid coil has been tested bin the aspects of resistor, laps, current, power and withstand
voltage.
German spectrometer
All the metal components of solenoid valve have been tested by OXFORD spectrometer to ensure the rightness of material, which
meets various requests for production
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
Iron-hand digital control lathe
High-tech iron-hand operating, each operator can manage more than 5 sets digital control lathes,which greatly improve the
production efficiency and sharply reduce the production cost. So we can offer more discount to the customer.
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
High performance digital automatic testing machine for solenoid valve
Each solenoid valve has been tested of high pressure, low pressure,leakage and so on, to ensure that we can offer satisfied
products for our customers.
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
solenoid valve assembly line
All the workshops are equipped with air conditioner, to create a clean, comfortable working environment for the employees.
Exhibition
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
EXPO exhibition in shanghai

1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
AQUATECH in beijing

Customer Photos
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty

AQUATECH IN Amsterdam

Packing & Delivery
1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty

Shockproof Bag to protect valve

1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty

Strong Cartons

1.English neutral packaging

2.with round star logo

3.with your logo (Charged)

1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty

membrane outside protect rain

Package more than 40kgs,use
Fumigated wooden case or pallet.

1 Inch Plastic Solenoid Water Valve AC220V IP65 3-Year Warranty
