Brass Miniature Solenoid Valve Pilot Operated Normally Open NO 24VDC 12VDC
Brass Miniature Solenoid Valve Pilot Operated Normally Open NO 24VDC 12VDC
Brass Miniature Solenoid Valve Pilot Operated Normally Open NO 24VDC 12VDC
Brass Miniature Solenoid Valve Pilot Operated Normally Open NO 24VDC 12VDC
Specifications
Brand Name :
Round Star
Model Number :
UD-C
Certification :
CE/ROHS/TUV/FDA
Place of Origin :
China
MOQ :
5pcs
Price :
negotiation
Payment Terms :
Western Union, MoneyGram, T/T
Supply Ability :
4,000pcs per month
Delivery Time :
5 working days after received your payment
Packaging Details :
exporting condition
working medium :
water
medium temperature :
-5 ～ 80℃
working pressure :
0.3～10bar
valvebody material :
brass
sealing material :
EPDM
interface :
G thread
working voltage :
24V
Description

brass miniature solenoid valve pilot operated normally open NO 24vdc 12v

The main features of the low-pressure solenoid valve is more beautiful, in the absence of stressful situations can also start, good sealing. Using authoritarian coil, when in use is not easily destroyed. Relative to other materials in terms of security is relatively high.

Brass Miniature Solenoid Valve Pilot Operated Normally Open NO 24VDC 12VDC

UD-series solenoid valve specification table

model

interface size

Orifice size

(mm)

Cv

 working pressure (bar) dimension valvebody material Weight(Kg)
NC NO

length×width×height

(mm)
AC220V DC24V AC220V DC24V
UD-2

1/8＂

1/4＂

 1.5 0.1 0 ～ 30 0 ～ 20 0 ～ 8 0 ～ 8 φ36×75 SS304 0.4
2.0 0.2 0 ～ 20 0 ～ 15 0 ～ 8 0 ～ 8 φ36×75 0.4
UD-3 3/8＂ 3.5 0.25 0 ～ 10 0 ～ 8 0 ～ 3 0 ～ 3 φ45×81 0.5
UD-C-10N 3/8＂ 10 3.2 0.3～ 10 0.3～5 0.1～13 0.1～13 45×31×86 copper,SS 0.4

Brass Miniature Solenoid Valve Pilot Operated Normally Open NO 24VDC 12VDC

Brass Miniature Solenoid Valve Pilot Operated Normally Open NO 24VDC 12VDC
