Specifications
Place of Origin :
Guangdong, China
Brand Name :
SHANGWEN
Model Number :
Outdoor button signal connector
Packaging Details :
10pcs/sample bag
25pcs/Blister box(23cm x 23cm)
500pcs/carton (51cm x 26cm x 34cm)
MOQ :
2 pieces
Price :
$3.20/pieces 2-99 pieces
Name :
Signal Connector Accessories
Type :
Adapter
Gender :
Female
Industrial electronics :
accessories
Frequency Range :
1 - 100 MHz
Description

Outdoor Button Female Male Plug Signal Rj45 Adaptor Connector For Cable Extensions

Products Description
etherCON feedthrough coupler for cable to cable extensions
Outdoor button signal connector

☑ Approved latch lock system
☑ Accommodates NE8MC* or any standard RJ45 plug
☑ NE8FF coupler (adapter) for cable to cable mating – use with NE8MC carriers or any standard RJ45 plug
1. Product parameters
Connection Type
Coupler (adapter)
Gender
Female
2. Electrical parameters
Contact resistance
< 10 mΩ
Dielectric strength
1 kVdc
Frequency Range
1 - 100 MHz
Insulation resistance
> 0.5 GΩ
Rated current per contact
1,5 A
Rated voltage
< 50 V
Standards compliant
TIA/EIA 586B, IEC11801
3. Mechanical parameters
Insertion force
≤ 20 N
Pull out force
≤ 20 N
Service life
> 1000 mating cycles
Locking device
Latch lock
4. Material and environmental parameters
Contacts
Bronze (CuSn8)
Contact plating
0.2 µm Au over Ni plating
Inner core
PBTP 15 % GR
Shell
AlMgSi 0.5, black plated
Clamping sleeve
CuZn35Pb2, tinned
Flammability
UL 94 HB
Temperature range
-30 °C to +80 °C
5. Assembly reference
Rj45 Adaptor Button Signal Connector Accessories For Cable Extensions
Rj45 Adaptor Button Signal Connector Accessories For Cable Extensions
Rj45 Adaptor Button Signal Connector Accessories For Cable Extensions
Rj45 Adaptor Button Signal Connector Accessories For Cable Extensions
Application area
Rj45 Adaptor Button Signal Connector Accessories For Cable Extensions
Company Information

The company has set up a connector factory in Ningbo and a finished wiring harness processing factory in Shenzhen. The monthly output of finished wiring harness can reach 500,000 pieces and the monthly output of connector canreach 300,000 sets.
