M15 Parallel One To Three 3 Pin Waterproof Connector Cable LED Driver Power Cable Assembly
M15 Parallel One To Three 3 Pin Waterproof Connector Cable LED Driver Power Cable Assembly
M15 Parallel One To Three 3 Pin Waterproof Connector Cable LED Driver Power Cable Assembly
M15 Parallel One To Three 3 Pin Waterproof Connector Cable LED Driver Power Cable Assembly
M15 Parallel One To Three 3 Pin Waterproof Connector Cable LED Driver Power Cable Assembly
M15 Parallel One To Three 3 Pin Waterproof Connector Cable LED Driver Power Cable Assembly
Specifications
Supply Ability :
Can produce 10 million sets of wire harnesses annually
Model Number :
M15F waterproof connector
IP Protection Rating :
IP67
MOQ :
10 sets
Delivery Time :
7-15 days
Contact Resistance :
≤5mΩ - 10mΩ
Payment Terms :
L/C,D/A,D/P,T/T
Price :
3 USD -5 USD
Housing Material :
Nickel-Plated Brass, Stainless Steel, Glass-Fiber Reinforced PA66 (Nylon)
Certification :
UL,CE certification
Contact Material :
Phosphor Bronze, Gold Plated
Brand Name :
kenhon
Withstand Voltage :
≥1000V AC (1 minute duration)
Place of Origin :
Shenzhen, Guangdong, China
Rated Voltage :
300V-600V
Packaging Details :
10*10*10
Description
M15 F-Type Parallel One To Three 3 Pin Outdoor Street Light Module Waterproof Connector

A 15 mm-class circular threaded interconnect with F-shaped distribution body for low-voltage LED power distribution, streetlight branch taps, and outdoor power connections where M12 is under-rated and M20 is oversized.

Key Benefits
10 A / 250-300 V capacity in compact 15-mm shell - handles 12/24/48 VDC LED strings and 220 VAC streetlight applications
Built-in branching capability - F-type body provides 1-in-2-out or 1-in-3-out distribution, eliminating separate junction boxes
IP67 standard / IP68 optional - Survives rain, hose-down, temporary immersion with silicone O-rings and threaded M15×1 nut
Field serviceable - Solder or screw termination accepts 0.3-1.5 mm² cables, enabling quick repairs and custom lengths
Technical Specifications
Parameter Specification
Coupling M15 × 1.0 threaded
Pin Configurations 2 / 3 / 4 / 5 / 2+3 (power ± signal)
Rated Current 10 A (2/3-pin), 15 A (2-pin 2.0 mm²), 5 A (4-pin), 10+5 A (2+3)
Rated Voltage 250 V / 300 V AC-DC (2-3 pin), 125 V (4-pin)
Contact Resistance ≤ 5 mΩ
Protection Rating IP67 standard / IP68 optional (mated)
Cable OD ≤ 8.5 mm (6.3-8.3 mm typical)
Operating Temperature -40 °C to +105 °C
Shell Material PA66+GF, UL94-V0
Certifications CE, RoHS, REACH, UL/TUV/CQC options
Competitive Advantages
  • vs M12 A-code: +150% current capacity (10 A vs 4 A), larger cable OD, built-in branching
  • vs M20 inline coupler: 30% smaller footprint, lower BOM cost, sufficient for LED-fixture applications
  • vs junction box + PG glands: Integrated sealed body provides 70% faster pole-top installation
  • vs generic DC barrel T-tap: Threaded M15 lock + O-ring superior for vibration, UV, and weather resistance
Applications
  • Outdoor LED & Street Lighting: Pole taps, luminaire chains, landscape lighting branches
  • Solar & Off-Grid: Solar streetlight feeds, PV combiner aux, battery pack taps
  • Building & Commercial: Shopping mall LEDs, exhibition lighting, architectural distribution
  • Industrial: 24 VDC valve/sensor clusters, conveyor systems, AGV auxiliary power
  • Marine / RV / Agriculture: Deck lighting, tractor implements, irrigation systems
  • Temporary & Event: Outdoor stage lighting, mobile performance setups, tent power distribution
