Specifications
Brand Name :
YICHENG
Model Number :
WDQ series
Certification :
CE
Place of Origin :
Guangzhou, China
MOQ :
one piece
Price :
negotiation
Payment Terms :
T/T, western union, L/C
Supply Ability :
1000000pcs/month
Delivery Time :
within one week
Packaging Details :
carton
Color :
Yellow and black
Connection :
1.2 inch and 2 inch
Type :
diving
pump body :
cast rion
Control :
Floating ball
Flow rate :
6 -20m3/h
Description

10m Head Automatic Sewage Pond Water Pumps With Floating Ball Control ON / OFF


Description:

WDQ series single-phase sewage submersible pump is currently the most advanced and ideal machine that USES suction under the structure of vortex flow, with non clogging, corrosion resistance, drain thoroughly, convenient and reliable, widely applicable, along with a floating ball can switch when unattended, realize automatic start-stop control; has the power distribution motivation for single-phase capacitor running asynchronous motor (or three-phase asynchronous motor); has thermal protector, met overtemperature and overpressure automatically cut off power supply; can be under bad environment to ensure the operation safety and reliability.
Application:

Applied to pumping such liquid which is not clean , with solid matter or long fibre matter.

It can be used:
1.for water supply from wells or reservoirs.
2.for domestic use.
3.for civil and industrial application.
4.for garden use and irrigation.
5.for draining slurry or waste water.

Material:

Pump body Cast iron
Impeller plastic
Motor housing Stainless steel
Motor wire Copper 100%
Mechanical Seal Ceramic & graphite
Shaft 2Gr13(AISI420)
Bearing NSK & China

Model Outlet Motor Power Voltage

Flow
rate

Max.
flow

 Head

Max
Head

 Flow section diameter Weight
　 (mm) (kw) (V) (m3/h) (m3/h) (m) (m) (mm) (kg)
WQD5-5-0.18F 40, 32 0.18 220 5 6 5 7.0 18 6.5
WQD5-5-0.25F 40, 32 0.25 220 5 9 5 7.5 　 9.0
WQD5-7-0.37F 40, 32 0.37 220 5 12 7 8.5 　 15.5
WQD5-7-0.45F 50, 40 0.45 220 5 12.5 7 10.0 25 17.5
WQD5-10-0.55F 50, 40 0.55 220 / 380 5 15 10 11.0 25 18.5
WQD10-10-0.75F 50, 40 0.75 220 / 380 10 18 10 12.0 30 19.5
WQD16-5-1.1F 50, 40 1.10 220 / 380 16 20 5 9.0 50 20.5
