Specifications
Brand Name :
YICHENG
Model Number :
DF15, DF20, DF25, DF40, DF50, DF65, DF80, DF100
Certification :
CE
Place of Origin :
Guangzhou, China
MOQ :
one piece
Price :
negotiation
Payment Terms :
T/T, western union, L/C
Supply Ability :
1000000pcs/month
Delivery Time :
within one week
Packaging Details :
carton, film
Material :
Brass material
Standard :
IP68 waterproof
Voltage :
DC24V
Type :
Two ways
Max pressure :
0.5Mpa
Temperature :
NBR: -10℃ ～ 80℃
Description

Brass Material Two Ways Solenoid Valve Water Fountain Accessories DC24V IP68 Waterproof

DF series, normally closed.With Coils F14B

Port Size Orifice Cv Min Pressure Max Pressure Seal Material Body Material Valve Body Coils
AC(28VA) DC(20W)
1/2″ 15 9.3 0.0MPa 0.5MPa 0.5MPa NBR Brass or Stainless Steel DF15XXX F14B
3/4″ 20 9.3 0.0MPa 0.5MPa 0.5MPa DF20XXX F14B
1″ 25 12 0.0MPa 0.5MPa 0.5MPa DF25XXX F14B
11/4″ 32 24 0.03MPa 0.5MPa 0.5MPa DF32XXX F14B
11/2″ 40 29 0.03MPa 0.5MPa 0.5MPa DF40XXX F14B
2″ 50 48 0.03MPa 0.5MPa 0.5MPa DF50XXX F14B

Description:

Characteristic:

1. with diaphragm construction for fountain use matched with watertight coil

2. Opening speed at 10 times per second

Medium: Water

Temperature: NBR: -10℃ ～ 80℃

Pressure: 0.03 ～ 0.5Mpa

Prot Size: 1/2″,3/4″,1″,11/4″,11/2″, 2″,F21/2″,F3″,F4″

Orifice(mm): DN15,20,25,32,40,50,65,80,100

Voltage: DC: 12V, 24V

AC: 220/230V, 110/120V, 12V, 24V (50/60HZ)

Coils: F14B, 8VA(AC), 20W(DC), IP68,100%ED

Advantage:

1. Wear resistance

2. Good sealing performance

3. Light switch

4. Long service life

Features:

1) Investment Casting Body And Cap

2) Working Pressure 1/2”~2” 1000PSI, 2” ~ 3” 800PSI

3) Adjustable Steals And Seats

4) Pure Teflon Seals And Seats

5) Blow-Out Proof Stem

6) 100% Leakage Tested At 100 OSI Air Under Water

7) Hydrostatic Test Pressure:

8) 1/2” ~ 2” 1500 PSI, 2 1/2” ~ 3” 1200PSI

9) Locking Device (Option)

Material:

Body: Brass

Seal: NBR, EPDM, PTFE or VITON

Armature: Stainless Steel 304

Stop: Brass

Plunger: Brass

Springs: Brass

Shading Rings: Brass
