Specifications
Brand Name :
EAST
Model Number :
Xa
Place of Origin :
China
MOQ :
1
Price :
Negotiable price
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Delivery Time :
10--60 workdays
Packaging Details :
Wooden box
Supply Ability :
100
Maximum Working Pressure :
≤ 1.6MPa
Flow Range :
3 ~ 2160m³/H; Head Range: 5 ~ 135m
Motor Protection Level :
IP55
Motor Insulation Class :
Class B or Class F
Description

Working Conditions and Standards

  • Flow range: 8 ~ 2640 m³/h
  • Head range: 4.5 ~ 150 m
  • Temperature range: -15°C ~ 80°C
  • Inlet and outlet diameters: 32mm ~ 500mm
  • Inlet pressure: ≤ 0.3MPa
  • Flange standard: GB/T 17241.6 - 2008 PN1.6MPa
  • When viewed from the drive end, the pump rotates clockwise.

XA Structure Diagram

  • Pump Cover
    • Self - flushing structure
  • Seal
    • Mechanical seal / packing seal
  • Pump Body
    • Made by resin sand molding to ensure performance
  • Shaft Sleeve
    • Stainless - steel shaft sleeve with high hardness
  • Self - flushing Hole
    • Flushes the mechanical seal / packing
  • Drainage Ring
    • Prevents water from entering the bearing
  • Bracket
    • Short - bracket design
  • Pump Body Seal Ring
    • Replaceable to prevent damage to the pump body
  • Bearing Pressure Cover
    • High strength
  • Impeller Nut
    • Uses a combination of wave - shaped washers for anti - loosening
  • Bearing
    • Strong load - bearing capacity
  • Impeller
    • Adopts a high - quality hydraulic model
  • Support Foot
    • Designed with U - shaped holes for easy installation
