Specifications
Brand Name :
Botai
Model Number :
P61103-104848
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
100
Delivery Time :
10 Working Days
Packaging Details :
Wooden box
Origio :
Tian Jin, China
Productioncapacity :
100000pieces/Year
Design Pressure :
2.2m/PA
Material Type :
SS304/SS316L
Description

The P61103-104848 Plate & Shell Heat Exchanger is a high-efficiency heat exchange device that combines the dual advantages of plate heat exchangers and shell-and-tube heat exchangers. Adopting the industry-proven fully welded process and a corrugated plate bundle core structure, it can adapt to the harsh heat exchange conditions of high temperature, high pressure and variable load across multiple industries, serving as a core supporting equipment for heat exchange and energy recovery in industrial production.

High-efficiency heat exchange of plate & shell heat exchangers

Core Structure and Working Principle

This product uses a plasma-welded corrugated plate pack as the core heat transfer element, which replaces the heat exchange tube bundle of traditional shell-and-tube heat exchangers and is integrated into a sealed shell. The rubber sealing gasket design is eliminated, and the hermetic isolation between plates is achieved through a fully welded process. During operation, the hot and cold fluids flow countercurrently in the independent flow channels formed by the plate bundle and the shell respectively. Relying on the high thermal conductivity and turbulence-enhanced design of the corrugated plates, efficient heat transfer is realized with a minimum heat exchange temperature difference of 1℃, and the heat exchange efficiency is far superior to that of traditional shell-and-tube heat exchangers.
High-efficiency heat exchange of plate & shell heat exchangers

Core Product Advantages

High Temperature and High Pressure Resistance for Harsh Working Conditions

High Efficiency and Compactness, Saving Space Costs

Stable Heat Exchange for Variable Load Conditions

Safe, Reliable and Long Service Life

Low Pressure Loss and Excellent Energy Efficiency

High-efficiency heat exchange of plate & shell heat exchangers

Application Fields

Relying on its excellent heat exchange performance and working condition adaptability, this product is widely used in heating, cooling, evaporation, condensation and waste heat recovery processes in various industrial fields:

  • Refrigeration industry: Ammonia refrigeration intermediate economizers, ammonia ice water evaporators, condensers/evaporators for carbon dioxide refrigeration systems, etc.;
  • Chemical industry: Ammonia water dilution heat exchange, synthetic ammonia heat exchange, liquefied natural gas heat exchange, rich and lean liquid heat exchange, DMP cooling heat exchange, etc.;
  • Coal chemical industry: Phase change and non-condensable gas cooling/heating, temperature and pressure swing adsorption processes, tar/kerosene cooling, etc.;
  • Food and beverage industry: Heat exchange in sugar production processes, beer cooling, low-temperature treatment of various beverages, etc.;
  • Energy/petroleum chemical/shipbuilding industry: Steam condensation, crude oil heating/cooling, gas heat exchange, waste heat recovery devices, marine oil coolers, etc.;
  • Pharmaceutical/metallurgical industry: Solvent condensers, reactor temperature control, heat exchange of metallurgical process media, etc.
High-efficiency heat exchange of plate & shell heat exchangers

Core Product Features

  • Process: Plasma laser welding, fully sealed and gasket-free design;
  • Material: High-quality corrosion-resistant plates + high-strength shell, supporting customized material selection;
  • Operation: Low pressure drop, little retained liquid, suitable for continuous operation under variable load;
  • Maintenance: Simple structural design, less scaling, low later maintenance cost, enabling quick overhaul.
