Specifications
Brand Name :
Botai
Model Number :
EC500-PHE
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
100
Delivery Time :
10 Working Days
Packaging Details :
Wooden box
Origio :
Tian Jin, China
Productioncapacity :
100000pieces/Year
Design Pressure :
2.2m/PA
Material Type :
SS304/SS316L
Description
Evaporator Industrial Heat Exchanger Recuperator Enfriador De Intercambiador
This industrial heat exchanger equipment features material and steam flow channels formed by alternating assembly of plates with identical specifications, sealed by gaskets or connected through welding. The plates serve as core heat transfer components, while the optimized flow channel design enables feed liquid to achieve highly efficient turbulent flow. Available in three assembly configurations to meet diverse industrial requirements based on application scenarios and material characteristics including corrosivity and pressure demands.
Available Assembly Types
  • Detachable Type: The mainstream configuration offering high heat transfer efficiency, cost-effectiveness, easy operation and maintenance, flexible evaporation area adjustment, and reduced precious metal consumption.
  • Semi-Welded Type: Balances sealing performance with partial disassembly capability, featuring partially welded and partially sealed plates. Ideal for production scenarios requiring enhanced corrosion resistance or sealing.
  • All-Welded Type: Complete welding between plates eliminates gaskets, providing superior sealing performance, high pressure tolerance, and excellent corrosion resistance for demanding chemical production and corrosive material processing.
Evaporator Industrial Heat Exchanger Recuperator Enfriador De Intercambiador
Core Product Advantages
Superior Heat Exchange Efficiency: Features a heat transfer coefficient 2-3 times higher than tubular evaporators. The plate flow channel design enables rapid turbulent flow, significantly improving heat exchange efficiency and achieving effective evaporation even with low temperature differentials.
Anti-Clogging and Anti-Scaling Design: Continuous turbulent flow across heat exchange surfaces constantly scours the surface, reducing fouling adhesion and extending scaling cycles. The equipment resists clogging, minimizing maintenance costs associated with frequent cleaning.
Compact Structure and High Space Utilization: Occupies only 1/3 to 1/4 the space of tubular evaporators with only 1/10 the height for equivalent evaporation capacity. Effectively overcomes industrial site space limitations and adapts to various installation environments.
Easy Maintenance and Expansion: Maintenance requires no complex procedures - simply loosen plate heat exchanger screws for disassembly, assembly, cleaning, and maintenance. Evaporation area can be flexibly adjusted by adding or removing plates without replacing main equipment, accommodating dynamic production scale changes.
Low Comprehensive Operating Costs: Overall design reduces precious metal consumption and manufacturing costs. Low heat loss and high heat transfer efficiency minimize heating media consumption, providing significant energy savings during long-term operation. Compact footprint reduces factory space requirements.
Evaporator Industrial Heat Exchanger Recuperator Enfriador De Intercambiador
Scope of Application
The EC500-PHE plate evaporator, with its multiple core advantages, is widely used across industrial evaporation markets. Suitable for evaporation processes including material concentration, solvent recovery, and wastewater treatment in food, pharmaceutical, chemical, light industry, environmental protection, and metallurgy sectors.
Particularly ideal for production scenarios requiring compact installation space, high heat exchange efficiency, and maintenance convenience. Effectively handles clean feed liquids with low to medium viscosity and excels in applications such as low-temperature concentration of heat-sensitive materials, conventional aqueous solution concentration, and high-salt wastewater treatment.
Evaporator Industrial Heat Exchanger Recuperator Enfriador De Intercambiador Evaporator Industrial Heat Exchanger Recuperator Enfriador De Intercambiador
