Specifications
Packaging Details :
wooden box or pallet
Function :
High-speed rotary labeling
Output :
250 BPM, based on 500mL ±100mL bottles
Weight :
Approx. 4000kg
Price :
2000~300000USD
MOQ :
1
Material :
SUS304
Supply Ability :
50 units per year
Support :
Customized（Color/Configuration）
Payment Terms :
L/C,T/T
Type :
Labeling Machine
Delivery Time :
30 working days to 180 workings days
Description
High Precision Hot Melt Round Bottle Labeling Machine | 60% Glue Saving & Low Maintenance

Designed for round bottle labeling in liquor, beverage, fruit juice, sauce and daily chemical industries, our automatic hot melt labeling machine is developed to help manufacturers cut costs and improve production quality. Equipped with eight high-precision servo motors and multi-servo synchronous control system, it supports quick fine-tuning of labeling head position with smooth operation and stable labeling precision. Featuring low failure rate during long-term operation, it greatly cuts downtime and manual adjustment cost. All models come with standard balancer and two separate automatic lubrication systems for main machine and labeling station, which automatically lubricate core moving parts regularly to reduce manual maintenance, slow component abrasion and extend equipment service life.

Stations 9 stations
Power Supply AC380V, 50Hz, 13KW
Production Speed 12,000–18,000 BPH (subject to the dimensional accuracy of containers and labels)
Speed Regulation Stepless speed control
Labeling Accuracy ±1mm (subject to container specifications)
Applicable Container Diameter ≤φ85mm
Paper Core Inner Diameter φ152.4 mm
Max Label Roll Diameter φ600 mm
Label Height H30-130mm
Label Thickness 0.045-0.05mm
Gluing Method Roller gluing, glue applied to both ends of labels
Melting Temperature 120–160℃
Label Materials OPP film, pearlescent film, paper-plastic composite film, paper labels
Air Source Requirement 5 kg/cm²
Overall Dimension Overall Dimension
Machine Weight 4000 kg

Outfitted with durable silent cutting blade with service life up to 26 million single-edge cuts, it delivers neat cutting without broken labels or jamming issues. The adjustable vacuum suction drum fits round containers of different sizes easily, enabling flexible production of multiple products on one single machine. Our self-developed energy-saving gluing unit is a standout advantage, reducing glue consumption by 60% versus conventional labelers to slash raw material expense. Less residual glue accumulation extends cleaning intervals and avoids frequent production halts. Optional automatic label splicing is available for high-speed unmanned production to boost overall line efficiency and output.
