Automatic Sorting 11KW 12 Paddles 180m3/H Ballistic Separator Machine
Automatic Sorting 11KW 12 Paddles 180m3/H Ballistic Separator Machine
Automatic Sorting 11KW 12 Paddles 180m3/H Ballistic Separator Machine
Automatic Sorting 11KW 12 Paddles 180m3/H Ballistic Separator Machine
Automatic Sorting 11KW 12 Paddles 180m3/H Ballistic Separator Machine
Automatic Sorting 11KW 12 Paddles 180m3/H Ballistic Separator Machine
Automatic Sorting 11KW 12 Paddles 180m3/H Ballistic Separator Machine
Automatic Sorting 11KW 12 Paddles 180m3/H Ballistic Separator Machine
Specifications
Brand Name :
Hengyang
Model Number :
HY-series
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
27
Delivery Time :
15-20 days
Packaging Details :
Negociated
Application :
waste materials
Color :
Blue
Capacity :
4-15t/h
Name :
Ballaistic Separator
Description

Ballaistic Separator for Waste Sorting Plant

The ballistic separator is typically installed as a starting machine of the automatic sorting line in waste recycling systems to increase the recovery rate and maximize the separation efficiency of the subsequent separators.
Application

The ballistic separator can be used for sorting following materials:

  • Combustibles, recyclables and backfill garbage
  • Glass bottles and ceramics
  • Plastic packages separated from film or paper
  • Inert impurities smaller than 10 mm

Materials can be separated:

  • Flat and light (2D) materials: film, paper, cardboard, textiles and fiber materials
  • Rolling and heavy (3D) materials: plastic containers, bottles, stones, wood, cans and metal materials
  • Debris: This material will be separated according to the particle size and diameter of the paddle perforations.

Tecnical Details:

Model Unit HY-40 HY-60 HY-80 HY－100 HY-120
Capacity m3/h 60 90 120 150 180
ton/h 4.8 7.2 9.6 12.2 14.4
Power consumption kw 5.5 7.5 11 11 11
Paddle length m 5.5 5.5 5.5 5.5 5.5
Paddle No. No. 4 6 8 10 12
Screen area m2 9.6 14.4 19.2 23.9 28.7
Power supply 380-400V, 50/60Hz
Dimension (W*L*H) m 2260*7955*1900 3050*7955*1900 3440*7955*1900 4180＊7955*1900 4625*7955*1900
Angle adjustment Range: 0～18° Option: auto/manual
Centralized lubrication Option: Auto/manual
Sieve size According to material and process
Covers Option: plastic/steel
Air support Option: 2-4 fans (frequency controlled)
Weight t 5.75 7 8.5 9.75 11
