| Features Highlight | 1. Vandal-Resistant Construction 2. Easy to Service Modular Design 3. All Weather Proof IP55 Enclosures 4. High-Brightness LCD Panel 5. LED Backlight with High Contrast 6. Automatically Adjust Monitor Brightness 7. Operating Temperature -20℃ to 45℃ 8. Intelligent surveillance | |
| LCD Parameter | Active Area(mm) | 1209*680(W×H) |
| Dot Pitch(mm) | 0.248*0.0.744(W×H) | |
| Display Color | 16.7M(8bit) | |
| Brightness | 1500cd/m2 | |
| Contrast | 3000:1(Typical) | |
| Response Time | 5ms(Typical) | |
| Technical Specification | ||
| Speakers | 2×10W | |
| Voltage Frequency | AC 108-115V,50/60Hz AC 208-240 V, 50/60 Hz | |
| PowerConsume(Max) | 1.3kW (Mainly for AC starting) | |
| Video inputs | VGA HDMI | |
| Audio Interface | AUDIO IN/OUT | |
| Auto Brightness Control | Yes (Optional) | |
| Temperature control system | Intelligent air conditioner | |
| Operating temperature range | -40°C to +55°CC19 | |
| Storage Temperature | 0°C~50°C | |
| Working humidity | 10% - 90% no condensation | |
| Storage temperature | '-20°C - 60°C | |
| Operating Humidity | 5% - 100% no condensation | |
