Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Anticorrosive M6C08 IPE Brushless DC Motor
Specifications
Place of Origin :
Guangdong, China
Price :
Negotiable
Brand Name :
GS
Model Number :
M6C08 IPE 130KV 180KV 260KV 320KV
Motor Model :
M6CO8 IPE V3.0
Motor size :
D:72 x 31.4 mm
Propeller Mounting Holes :
D:12 M3x4,D:18 M3x4.D:22 M3x4
Shaft Diameter :
IN: 6 mm
Bearing :
EZ0 696ZZ*2
Number of pole pairs :
14
Cable Length :
150 mm 16# Awg(Black)silicone
Rotor Balance :
≤5 mg
Motor Balance :
≤10 mg
Motor Mounting Holes :
D:25 M3x4
Disruptive test :
500 V
Description
Anticorrosive M6C08 IPE Brushless DC Motor
Product Specifications
Attribute Value
Motor Model M6CO8 IPE V3.0
Motor size D:72 x 31.4 mm
Propeller Mounting Holes D:12 M3x4,D:18 M3x4.D:22 M3x4
Shaft Diameter IN: 6 mm
Bearing EZ0 696ZZ*2
Number of pole pairs 14
Cable Length 150 mm 16# Awg(Black)silicone
Rotor Balance ≤5 mg
Motor Balance ≤10 mg
Motor Mounting Holes D:25 M3x4
Disruptive test 500 V
Product Description

The M6C08 IPE brushless DC motor is engineered for high-performance applications with a payload capacity of 1.5-3kg and supports 6S, 8S, and 12S voltages. Its innovative 24N28P stator design has passed rigorous magnetic flux density simulation tests, ensuring optimal energy efficiency.

Anticorrosive M6C08 IPE Brushless DC Motor Anticorrosive M6C08 IPE Brushless DC Motor Anticorrosive M6C08 IPE Brushless DC Motor Anticorrosive M6C08 IPE Brushless DC Motor
Our Services
1 Year Warranty included for all purchases
14-day return policy for unsatisfied customers (contact required before return)
Free replacement for defective items within 3 months
Post-warranty support available (shipping fees apply)
Anticorrosive M6C08 IPE Brushless DC Motor
Frequently Asked Questions
Q1: Do you support OEM/ODM?
A1: Yes. We can print your logo on the product.
Q2: About samples.
A2: Samples ready in 7 days (10-20 days for OEM/ODM). Sample fee and shipping charged.
Q3: What is the delivery time?
A3: Regular orders ship in 15 days, OEM/ODM in 25-45 days (quantity dependent).
Q4: What is the minimum order quantity?
A4: No MOQ - wholesale orders accepted from 1 piece, including OEM/ODM.
Q5: What are your payment terms?
A5: L/C or 100% TT payment accepted.
Q6: Can you reduce the shipping cost?
A6: We always select the most economical shipping option. Customers may arrange their own shipping if preferred.
Q7: Return policy.
A7: Returns must be initiated within 7 days of receipt. Items must be in original condition with shipping costs covered by customer.
