10x Optical Zoom 2-Axis Stabilized Gimbal Camera with 640×512 Thermal Imaging and IP Output
10x Optical Zoom 2-Axis Stabilized Gimbal Camera with 640×512 Thermal Imaging and IP Output
10x Optical Zoom 2-Axis Stabilized Gimbal Camera with 640×512 Thermal Imaging and IP Output
10x Optical Zoom 2-Axis Stabilized Gimbal Camera with 640×512 Thermal Imaging and IP Output
10x Optical Zoom 2-Axis Stabilized Gimbal Camera with 640×512 Thermal Imaging and IP Output
10x Optical Zoom 2-Axis Stabilized Gimbal Camera with 640×512 Thermal Imaging and IP Output
Specifications
Brand Name :
GS
Model Number :
DYD10G613
Place of Origin :
Made in China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
100
Delivery Time :
6-8
Voltage :
DC 12V-26.2V
Power :
Dynamic 6.5W
Pitch action range :
-25~+110°
Yaw angle action range :
-140°～ +140°
Support mode :
1080P 30 fps
Resolution ratio :
640×512 pixel
Wavelength Range :
8～14μm
Minimum tracking target size :
16×16 pixels
Maximum tracking target size :
256×256 pixels
Maximum occlusion time :
2 seconds
Description
10x Visible Light Optical Zoom Camera 2-Axis Stabilized IP Output Gimbal
Advanced integrated dual sensor camera system with professional high-precision two-axis stabilization gimbal, Ethernet IP output, and IP control.
Product Specifications
Attribute Value
Voltage DC 12V-26.2V
Power Dynamic 6.5W
Pitch action range -25~+110°
Yaw angle action range -140°～ +140°
Support mode 1080P 30 fps
Resolution ratio 640*512 pixel
Wavelength Range 8～14μm
Minimum tracking target size 16*16 pixels
Maximum tracking target size 256*256 pixels
Maximum occlusion time 2 seconds
Product Overview

The DYD10G613 is an advanced integrated dual sensor camera system featuring:

  • 10x optical zoom CMOS sensor with 9x digital zoom (90x total hybrid zoom)
  • 13mm focal length 640*512 uncooled thermal imaging sensor with 9x digital zoom
  • Professional high-precision two-axis stabilization gimbal
  • Ethernet IP output and IP control
Key Features
Feature Capability
90x hybrid zoom 640*512 thermal imaging
4 picture-in-picture modes Menu adjustment parameters
10 thermal imaging pseudo-color modes Micro-sd card dual-channel recording
Technical Specifications
  • 2-Axis stabilized PTZ
  • 10X Optical Zoom, 9x Digital Zoom
  • 640*512 Thermal Imaging Sensor
  • AI Target Detection and Tracking (Tracking version)
  • TF card Recording & Photograph
  • Includes ground control software/App for real-time monitoring and control
Product Structure
10x Optical Zoom 2-Axis Stabilized Gimbal Camera with 640×512 Thermal Imaging and IP Output
Product Diagram
10x Optical Zoom 2-Axis Stabilized Gimbal Camera with 640×512 Thermal Imaging and IP Output
Warranty & Services
  • 1 Year Warranty included
  • 14-day return policy for unsatisfied customers
  • Free replacement for defective items within 3 months
  • Post-warranty repair service available (shipping fee applies)
10x Optical Zoom 2-Axis Stabilized Gimbal Camera with 640×512 Thermal Imaging and IP Output
Frequently Asked Questions
Do you support OEM/ODM?
Yes. We can print your logo on the product.
About samples.
Samples ready within 7 days (10-20 days for OEM/ODM). Sample fee and shipping charged.
What is the delivery time?
Regular orders ship within 15 days, OEM/ODM within 25-45 days.
What is the minimum order quantity?
No MOQ - wholesale orders accepted from 1 piece.
What are your payment terms?
L/C or TT 100% payment accepted.
