ICT3310D-8G2NAC XPON MDU 8GE Enterprise Gateway Router With Realtek Chipset
ICT3310D-8G2NAC XPON MDU 8GE Enterprise Gateway Router With Realtek Chipset
ICT3310D-8G2NAC XPON MDU 8GE Enterprise Gateway Router With Realtek Chipset
ICT3310D-8G2NAC XPON MDU 8GE Enterprise Gateway Router With Realtek Chipset
Specifications
Brand Name :
V-solution
Model Number :
ICT3310D-8G2NAC
Place of Origin :
Guangdong, China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
Negotiable
Supply Ability :
1000 pcs/day
Delivery Time :
3-5 days
Packaging Details :
Carton
Product :
1XPON + 8GE + ac WiFi
Chipset :
RTK9607C
PON :
Downstream rate 2.5Gbps, Upstream rate 1.25Gbps,EPON/GPON Dual Mode
Sensitivity :
<-27dBm CLASS B+
LAN :
8 *10/100/1000Mbps
Material :
Waterproof plastic shell
Description

XPON MDU Enterprise Gateway XPON+8GE With Realtek Chipset ICT3310D-8G2NAC

Product Description

ICT3310D-8G2NAC XPON+8GE+WiFi is a broadband access device designed to meet the needs of users for multiple business integration.

ICT3310D-8G2NAC product is based on the PON technology mature and stable, high cost performance, combined with WIFI5 wireless technology(2.4GHz/5Ghz Dual Band),8 GE ports, high reliability, easy management and good Quality of Service (QoS) guarantees, etc.

ICT3310D-8G2NAC XPON MDU 8GE Enterprise Gateway Router With Realtek Chipset

Technical Specifications

  • Dual mode(EPON/GPON)
  • Routing ONU/ONT
  • Best WiFi coverage
  • Good voice quality
Model

Dimension

(L * W * H)

 Power Power Consumption

ICT3310D-8G2NAC

(Waterproof plastic shell)

 196*160*32mm DC 48V, 2.5A ≤130W

Application

Pannel Lights

LED Mark Color Status Description
Power PWR Green On Device is powered on and starting.
Off Device is powered off.
WIFI WIFI Green On WiFi(2.4Ghz or 5Ghz) is on.
Off WiFi(2.4Ghz or 5Ghz) is off.
PON Register PON Green On ONU is registered to OLT.
Off ONU is not registered to OLT or Power off.
Blink ONU is registering to OLT.
Loss of Signal LOS Red On Optical signal could not be detected.
Off Optical signal is received normal.

Parameter Hardware Parameter

XPON

Chipset

 RTL9607CP
PON SC single-mode/single-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps,EPON/GPON Dual Mode
Wavelength Tx 1310nm, Rx 1490nm
Sensitivity <-27dBm(CLASS B+)
Optical Type

SC/UPC

PC
Interface Type 8 *10/100/1000Mbps Auto adaptive Ethernet interfaces, Full/Half Duplex, RJ45 connector(4 GE Option).
WiFi Interface

Compliant with IEEE802.11b/g/n/ac

2.4GHz Operating frequency: 2.400-2.483GHz

5.0GHz Operating frequency: 5.150-5.825GHz

Support: multiple SSID

Indicators

4, For POWER /WIFI / PON /LOS
