Specifications
Brand Name :
VP / No Logo / Customize brand / OEM / ODM
Model Number :
12V-200AH
Certification :
UL1642 UN38.3 MSDS CE ISO RoHS IEC
Place of Origin :
China
MOQ :
10-100Units
Price :
Negotiable
Payment Terms :
T/T D/P L/C
Supply Ability :
3000 Units/Month
Packaging Details :
PP bag inside, carton box outside/Carton
Product Name :
Custom Lithium Battery Pack Manufacturer BMS protection
Cell :
Tier 1 lithium battery cells
Customization :
Operation Voltage, Dimensions, Energy, Enclose Protection Rate
Communication :
Bluetooth
Circling Lifetime :
over 6000 cycles
Battery type :
Lifepo4 battery, lifepo4 12v 100ah, Lithium pack
Shell Protection Grade :
IP54
OEM / ODM :
Support
Rated Capacity :
100ah 200ah, 300ah,400ah, 600ah, 50ah
Battery Protection :
Intelligent BMS
Application :
Solar Street Light , Agricultural irrigation, Car Jump Starter , Electric lawn mower , Electric Wheelchair , Marine Cranking , RV Electric , Motorcycle , Cleaning robot
Description
LFP Battery Pack 12v Lithium Iron Phosphate Cells 200ah 2560Wh

Why Chooes vp batteries?

One-stop battery manufacturer: Alkaline, Zinc Carbon, NiMH, Button cell, Lithium, Li-polymer, rechargeable packs & ESS.

Annual capacity in billions – ready for any order size. Stable, affordable quality with timely supply.

LFP Battery Pack 12v Lithium Iron Phosphate Cells 200ah 2560Wh Energy Auto Battery

Guangzhou Victory Technology – Providing you with comprehensive battery partner support, from product development to market sales. We cordially invite you to visit our factory.

Product Parameters
Product Performance 12V-200AH
Standard Voltage 12.8V
Rated Capacity 200AH
Operating Voltage 10.8V-14.6V
Standard Charging Current 50A
Maximum Charge / Discharge Current 100A
Operating Temperating Range 0-40℃(Charge) -20-40℃(Discharge)
Storage Temperature -10℃-35℃(1Month) 25±2℃(3Month) 65%±20%RH
Cycle Life 6000
Communication Bluetooth
Waterproof Grade IP54
Humidity Range 5~95%
Net Size 522*240*218mm
Net Weight 22±3KG

Provides a stable DC power supply for power and telecommunications central stations, cellular towers, and network transmission equipment, ensuring the continuous operation of wired, wireless, and television signals.

LFP Battery Pack 12v Lithium Iron Phosphate Cells 200ah 2560Wh Energy Auto Battery

Basic Info.

  • At normal room temperature (approximately 25°C), the monthly self-discharge rate is less than 3%. This means your stored energy stays ready for months without frequent top-ups—ideal for seasonal applications, emergency backup systems, and inventory storage in hot climates.
  • Built-in intelligent battery management system (BMS) provides overcharge protection and short circuit protection.
  • Thanks to the stable lithium iron phosphate chemistry, even under harsh conditions such as severe impact, overcharging, or short circuits, there is a very low risk of explosion or fire.

LFP Battery Pack 12v Lithium Iron Phosphate Cells 200ah 2560Wh Energy Auto Battery

Product Description

By adopting an industrial-grade BMS solution, the core protection logic response time is controlled within 100ms, which can effectively block security risks. Meanwhile, based on the high-precision front-end sampling circuit, we can provide high-precision data monitoring throughout the entire life cycle, with the voltage sampling deviation always maintained at the 0.01V level, ensuring that every unit of electricity usage is transparent and controllable. High discharge current, lightweight design, and long cycle life outperform lead-acid.

LFP Battery Pack 12v Lithium Iron Phosphate Cells 200ah 2560Wh Energy Auto Battery

More Choices

Covering all common lead-acid lithium batteries: 12V-100AH (260*168*210), 12V-100AH (330*171*215), 12V-314AH, 12V-280AH, and 12V-628AH. A solution for RVs, marine, telecom, and solar storage.

LFP Battery Pack 12v Lithium Iron Phosphate Cells 200ah 2560Wh Energy Auto Battery

People Also Ask

Q: 100Ah vs. 200Ah LiFePO4 battery: which is better?

A: There is no absolute "better". It depends on your installation space constraints, budget, and weight sensitivity.
100Ah advantages: High modularity; easily handled by one person (~10-12kg); ideal for tight spaces or flexible expansion (e.g., small RVs, portable power).
200Ah advantages: Higher integration; fewer cables and BMS nodes; a cleaner system with a generally better cost-per-Wh ratio. Ideal for large storage (e.g., home off-grid stations, large vessels).

Q: Can LiFePO4 batteries be charged below 0°C (32°F)?

A: Generally, no. Standard LiFePO4 cells are prohibited from charging below 0°C. Forced charging at low temperatures can cause lithium plating on the negative electrode, forming lithium dendrites. These dendrites can not only cause permanent capacity degradation of the battery, but may also puncture the separator, leading to internal short circuits and thermal runaway.

Q: What is the cycle life of a 12.8V LiFePO₄ battery?

A: At 80% depth of discharge (DOD), the cycle count exceeds 4000. This means over 10 years of service life with one cycle per day, far exceeding the 2 years of lead-acid batteries.

Q: How to upgrade a 12V lead-acid system to LiFePO₄ system?

A: The main steps include selecting a voltage-matched (12.8V) LiFePO₄ battery, verifying compatibility with your existing charging equipment or replacing it with a dedicated lithium charger, ensuring the BMS supports the required current, and checking battery dimensions and cables. After upgrading, you gain lighter weight, longer life (>6000 cycles), and better discharge performance.

Q:Are your factory or trading company?

A:We are professional battery manufacturer with our own factory and brand. We provide all kinds of OEM/ODM services for distributors all around the world.

Ready to Specify or Private Label? Contact our B2B sales team for:

  • Volume-based commercial quotations.
  • Detailed OEM / ODM service guide.
  • Full technical documentation and certification packages.
