Specifications
Brand Name :
VP
Model Number :
VP-W
Certification :
MSDS CE IEC UN38.3
Place of Origin :
China
MOQ :
10-100Units
Price :
Reconsideration
Payment Terms :
MoneyGram,Western Union,T/T,D/P,L/C
Supply Ability :
3000Units/day
Delivery Time :
5-15days
Packaging Details :
PP bag inside, carton box outside/Carton
Product Name :
High Stability Solar Lithium LiFePO4 Battery
Cycle Life :
More than 6000 Times
Case material :
Metal
Battery Protection :
Smart BMS module
Protective function :
Over-current ,Over-voltage,Low-voltage ,Over-temperature ,Low-temperature protection,Short-circuit protection etc
Out current :
Pure sine wave AC output
Standard Capacity :
100Ah/ 51.2V
Protection mode :
Dual hardware protection
Description

6000 Cycle Life LiFePO4 Energy Storage Solar Lithium Battery Power Bank


Quick Detail:


· One-stop residential energy storage solutions
· All product adopt LiFeP04 cell
· Protocol Selection via Display Terminal
· BMS intelligent protection
· Multi-Module Expansion Support


Specifications:


PRODUCT PERFORMANCE

VP-S

VP-R

VP-W

STANDARD VOLTAGE

51.2V

RATED CAPACITY

100AH

OPERATING VOLTAGE

42V-58.4V

STANDARD CHARGING CURRENT

100A

MAXIMUM CHARGE/DISCHARGE CURRENT

50A

OPERATING TEMPERATURE RANGE

0-40℃(CHARGE) -20-40℃(DISCHARGE)

STORAGE TEMPERATURE

-10℃-35℃(1MONTH) 25±2℃(3MONTH)65%±20%RH

CYCLE LIFE

≥80% CAPACITY AFTER 6000 CYCLES AT 0.5C/25℃,100% DOD

COMMUNICATION

CAN&RS485

WATER PROOF GRADE

IP20

HUMIDITY RANGE

5~80%

NET SIZE

565*440*170MM

CARTON PACKAGING

650*490*235MM

PALLET

1 *1.2*1.5M

PER CARD BOARD

24BOX

20-FOOT CONTAINER

240BOX

40-FOOT CONTAINER

480BOX

NET WEIGHT

56.2±3KG

PACKING WEIGHT

59KG


Description:


1. Under normal conditions, using lithium iron phosphate battery technology, with excellent safety, 6 thousands of cycles, 100% DOD.
2. Built-in automatic protection function to prevent overcharging, overdischarging, overcurrent and overheating.
3. Maintenance free.
4. Internal battery balance.
5. Light weight: about 40%~50% of the weight of lead-acid batteries.
6. Can be charged using most standard lead acid charge (set).

7. Wide temperature range: -20 ° C ~ 60 ° C.
8. Support for series application extensions (up to 51.2V) and two parallels.

VP batteries come equipped with advanced monitoring and control systems that provide real-time data on battery performance, temperature, and other critical parameters, ensuring optimal battery operation and extending its lifespan. These batteries are versatile and can be used in various applications, including backup power for data centers, telecommunications equipment, and renewable energy systems.



Notices:


1. Prohibited to install in flammable environments, humidity > 80% or dusty areas.
2. Use flame-retardant cables for battery connection, with clear positive and negative pole markings to prevent short-circuit hazards.
3. Maintain ambient temperature: 0-40°C (charging), -20-40°C (discharging).
4. Maintain 20-80% SoC for cycle life preservation.
5. Avoid direct sunlight to accelerate the aging of the shell.



Applications:


Solar-Wind Power System / City Grid (On/Off) / Community and Family / Telcom Base / CATV system / Computer Server Center / Medical Instrument


6000 Cycle Life LiFePO4 Energy Storage Battery VP Solar Lithium Battery Power Bank


FAQ


Q1 : Are you a manufacturer or a trading company?
A1 : We are manufacturer.


Q2 : How do we ensure quality?
A2 : Our products meet global safety and quality standards, certified by KC, CB, CE, PSE, FCC, RoHS, and UN38.3, ensuring top-tier reliability and customer satisfaction worldwide.



Q3 : What is the shipping methods?
A3 : By sea, by air, by courier, by train.


Q4 : Is the price negotiable?
A4 : Yes, the price is negotiable. But the prices we give is based on the cost and it is quite reasonable, we can give discounts, but not much. And the Prices also have great elationship with the order quantity and material.


Q5 : What informations should i provide to make an order?
A5 : Usually, we need to know the voltage, the current and the size and quantity.



If you have any other questions, please feel free to contact us. Welcome your inquiry .
