Single phase Voltage transformer 630VA 220v Step down 24V 36V Control Transformer
Single phase Voltage transformer 630VA 220v Step down 24V 36V Control Transformer
Single phase Voltage transformer 630VA 220v Step down 24V 36V Control Transformer
Single phase Voltage transformer 630VA 220v Step down 24V 36V Control Transformer
Single phase Voltage transformer 630VA 220v Step down 24V 36V Control Transformer
Single phase Voltage transformer 630VA 220v Step down 24V 36V Control Transformer
Single phase Voltage transformer 630VA 220v Step down 24V 36V Control Transformer
Single phase Voltage transformer 630VA 220v Step down 24V 36V Control Transformer
Specifications
Brand Name :
SHLEIPUSI Or Support OEM/ODM Service
Model Number :
BK-630VA
Certification :
CE;ISO9001;UL
Place of Origin :
Shanghai
MOQ :
1
Price :
1 pc≤Qty≤5 pcs 60USD; 5 pcs＜Qty≤100 pcs 57USD; 100pcs＜Qty 55USD
Payment Terms :
T/T,D/P,D/A,L/C,Western Union,Alipay,Wechat pay
Supply Ability :
1000000PCS
Delivery Time :
1 pc≤Qty≤5 pcs 1-7 working days; 5 pcs＜Qty≤100 pcs 7-14 working days; 100pcs＜Qty More than 14 working days
Packaging Details :
Non-fumigation plywood case ; Reference packing size: 16X15X16CM; Reference weight: 12KG
Product name :
630VA Single Phase Step Down Control Transformer
Place of origin :
Shanghai, PRC
Rated capacity :
630VA or customized
Product model :
BK-630VA or customized
Rated input voltage :
380V 220V 480V Or Customized
Output voltage :
110V 220V 72V Or customized
Output precision :
2%
Working temperature :
－15℃~＋45℃
Noise :
≤50DB
Description

630VA Single Phase Step Down Control Transformer | SHLEIPUSI OEM/ODM Manufacturer

Product Introduction

Our 630VA Single Phase Step Down Control Transformer is a high-reliability, high-efficiency power conversion solution engineered for global industrial, commercial, and residential applications. Precision-built for stable voltage regulation, this BK-630VA transformer is ideal for CNC machines, laser cutters, photovoltaic systems, diamond cutting equipment, elevators, medical devices, blenders, generators, and factory automation setups. It supports full-capacity continuous operation, fully customizable input/output voltages to match global power standards, and is backed by international certifications and a 2-year warranty for long-term peace of mind.

Key Features & Advantages

  • High-Efficiency Core & Winding: Adopts a new high-permeability silicon steel core for noise-free operation, high magnetic flux, and ultra-low energy loss, paired with high-purity winding material for superior conductivity, low temperature rise, and consistent full-capacity performance.
  • Industrial-Grade Safety & Insulation: Built with premium insulation materials that withstand 3500V voltage tests, Class H insulation rating, and a high-quality nylon frame for exceptional dielectric performance. Reinforced terminals with robust insulation, durable heavy-duty construction, and user-friendly wiring design ensure safe, long-term operation.
  • Eco-Friendly Energy-Saving Design: Features optimized low no-load loss, high energy efficiency, and zero additional waveform distortion with ±2% output precision. Fully compliant with global environmental protection standards, delivering long-term cost savings for continuous operation.

Why Choose SHLEIPUSI

As a professional transformer manufacturer serving the global market, we offer full OEM/ODM services, including custom parameters, appearance, logo branding, and packaging to meet your unique needs. Every unit undergoes strict multi-stage quality inspection from raw material intake to final shipment, ensuring zero defects. We boast a monthly capacity of 10,000 low-power units and 2,000 high-power units, with a minimum order quantity of just 1 unit to support sample and bulk orders. We provide free professional product photography, flexible global shipping with all mainstream trade terms, 2-year warranty, and lifetime free technical support via phone, video, or on-site engineer service.

Technical Specifications

Parameter Details
Product Name 630VA Single Phase Step Down Control Transformer
Brand SHLEIPUSI / OEM/ODM Customizable
Model BK-630VA / Customizable
Rated Capacity 630VA / Customizable
Rated Input Voltage 380V, 220V, 480V / Customized
Rated Output Voltage 110V, 220V, 72V / Customized
Working Frequency 50/60Hz
Insulation Class Class H
Output Precision ±2%
Waveform Distortion No Additional Distortion
Working Temperature -15℃ ~ +45℃
Cooling Method Dry Type Air Cooling
Certifications ISO9001, CE, UL
Warranty 2 Years

Single phase Voltage transformer 630VA 220v Step down 24V 36V Control Transformer

Single phase Voltage transformer 630VA 220v Step down 24V 36V Control Transformer

Single phase Voltage transformer 630VA 220v Step down 24V 36V Control Transformer


Frequently Asked Questions (FAQ)

  1. How long is the lead time?

    Normally 3-7 working days for standard products; custom orders take 10-30 days based on quantity and requirements.
  2. How do you control product quality?

    We conduct professional inspection at every production stage, only shipping products that fully meet international standards.
  3. What are your payment terms?

    30% deposit for standard products, 50% advance for custom orders, with balance paid before shipment.
  4. Can you provide installation technical support?

    Yes, our professional technical team offers full installation guidance via video, phone, or on-site engineer service.
  5. What packaging do you use?

    Large products use reinforced wooden cases; small products use high-strength cartons for transit protection.
  6. Can you print our logo on the transformer?

    Yes, we accept full OEM/ODM, with custom logo placement on products, manuals, and documents for bulk orders.
  7. What is your main global market?

    Our products are sold worldwide, covering Asia, Africa, South America, North America, and Europe.
  8. What is your monthly production capacity?

    10,000 units for low-power transformers, 2,000 units for high-power models monthly.
  9. What is your minimum order quantity?

    Our MOQ is 1 set, supporting both sample testing and bulk procurement.
  10. What certifications do your transformers have?

    Our 630VA control transformers are ISO9001, CE, and UL certified, complying with global industrial safety standards.
  11. Can this transformer work with 50Hz and 60Hz systems?

    Yes, it is designed for 50/60Hz dual frequency, suitable for global power grid standards.
  12. Is this transformer suitable for PV systems and precision equipment?

    Absolutely, it is widely used in PV systems, laser cutters, and precision devices, with stable output to protect sensitive equipment.
