SR3003 Installation technology losses in different pipes Thermal Training Equipment

1. Overview

Brand: ShouldShine

Model:SR3003

investigation of the pressure losses of flow through pipes

- measurement of the pressure differential on different pipe sections

- influence of various pipe diameters

- influence of different materials and surface roughness

- effect of the flow velocity

- comparison between experiment and theory

2. Specification

[1] investigation of friction-induced pressure losses in flow through pipes

[2] pipe elements are commercially standard components in heating and sanitary engineering

[3] clear panel mounted on a sturdy, movable frame

[4] four measuring sections with different pipe crosssections and materials

[5] pipe sections can be selected via ball valves

[6] water connections made using quick-release couplings in the inflow and return

[7] flow can be adjusted via valves

[8] flow measurement using rotameter

[9] differential pressure measurement via differential pressure meter with display

3. Technical Data

Pipe sections measuring length: 1000mm

- pipe section 1: transparent plastic, diameter: 20x1,5mm

- pipe section 2: steel, diameter: 1/2"

- pipe section 3: copper, diameter: 18x1mm

- pipe section 4: copper, diameter: 15x1mm

Differential pressure meter

Measuring ranges- flow rate: 150...1600L/h- differential pressure: -350mbar...350mbar

Dimensions and Weight LxWxH: 1650x700x1850mm Weight: approx. 192kg

Required for Operation

Water connection: 1500L/h, drain
