Ethernet Wireless Bridge IP MESH WebUI 24V 48V POE
Ethernet Wireless Bridge IP MESH WebUI 24V 48V POE
Ethernet Wireless Bridge IP MESH WebUI 24V 48V POE
Ethernet Wireless Bridge IP MESH WebUI 24V 48V POE
Specifications
Channel Bandwidth :
20M/40MHz/80MHz/160MHz
Payment Terms :
T/T,PayPal
Price :
USD, RMB
Model Number :
MANET3718-W
Frequency :
5.8GHz, 5.2GHz, 2.4GHz
Interface :
LAN*3, Antenna*8
Brand Name :
OEM
Certification :
CE
Place of Origin :
Shenzhen China
MOQ :
1
Supply Ability :
1000pcs/Month
Delivery Time :
Negotiable
Packaging Details :
Brown Carton
Receiving Sensitivity :
Max -96dBm
Description

600Mbps 5G/2.4G Wireless Ethernet Bridge IP MESH WebUI 24V/48V PoE


Introduction

The MANET3718-W is a high-performance three-band MESH wireless bridge based on Qualcomm 11AC Wave2.0, which integrates two independent non-interference 802.11ac Wave2.0 5G modules and a 2.4G WiFi module. Supports three-band simultaneous work, 5G_L and 5G_H can be used as MESH dual links at the same time, and 2.4G can be used for independent coverage. It can be widely used in various projects that require high-speed bridging, multi-hop relay, large-capacity access, and fast roaming.


Features

■ Independent tri-band 802.11AC Wave2.0, support 5G band MESH dual-link networking and 2.4G/5G dual-band WiFi coverage

■ Supports MU-MIMO

■ Supports TDMA time division multiple access (point-to-multiple mode)

■ Large-capacity access, the number of clients that can be connected to the tri-band is more than 200

■ Supports 802.11KV automatic roaming protocol

■ Supports WAPI encryption

■ Scalable 4/5G public network access


Applications

■ Tunnel

■ Pipe Gallery

■ Oilfield

■ Mine

■ Hall/Stadium

■ Industrial Automation

■ Park

■ Farm

■ Fleet Networking



Specification

Data Rate Max 600Mbps
Modulation

DSSS/CCK BPSK/QPSK OFDM

BPSK/QPSK/16-QAM/64-QAM/256-QAM
Wireless Protocol 802.11ac Wave2.0
Frequency Band 5G_L, 5G_H and 2.4G
Frequency 5.8GHz, 5.2GHz, 2.4GHz
Receiving Sensitivity Max -96dBm
Channel Bandwidth 20M/40MHz/80MHz/160MHz
Range (each unit) ≥5000m (omnidirectional antenna)
Access Capacity ≥200 units
Configuration Method WebUI
PC Platform MESHCOM (under developing)
Working Humidity 5% ~ 95% (non-condensing)
Weight

w/o antenna: 2.3kg

w/ antenna: 2.8kg
Dimensions 230x200x60mm (L x W x H)
Power Supply 24V or 48V POE (IEEE802.3af)
Interface

LAN*3

Antenna*8
