DVI Fiber Optic HDMI Extender 2KM LC KVM DVI Extender Over Fiber
DVI Fiber Optic HDMI Extender 2KM LC KVM DVI Extender Over Fiber
DVI Fiber Optic HDMI Extender 2KM LC KVM DVI Extender Over Fiber
DVI Fiber Optic HDMI Extender 2KM LC KVM DVI Extender Over Fiber
DVI Fiber Optic HDMI Extender 2KM LC KVM DVI Extender Over Fiber
DVI Fiber Optic HDMI Extender 2KM LC KVM DVI Extender Over Fiber
DVI Fiber Optic HDMI Extender 2KM LC KVM DVI Extender Over Fiber
DVI Fiber Optic HDMI Extender 2KM LC KVM DVI Extender Over Fiber
Specifications
Brand Name :
LINK-MI
Model Number :
LM-THF122DKM
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union, PayPal, Bank Transfer
Delivery Time :
5-7 work days
Packaging Details :
White/Brown/Color Box
Model No. :
LM-THF122DKM
Standards :
DVI 1.0;
Maximum data rate :
10Gbps
Resolution range :
Up to 1920X1200@60Hz
Connector :
DVI-D
Interface :
LC connector
Signal type :
Stereo
Fiber type :
Single-mode a pair fiber
Wavelength :
Single-mode 1310nm
Transmission distance :
standard 2km
Description

DVI Fiber Optic Extender 2KM LC KVM DVI Extender over Fiber

Introduction

LINK-MI LM-THF122DKM Fiber optic extender provides extension of DVI signals long distances over one fiber optic cable, it supports high resolution up to 1920*1200, EDID copy, KVM signal and external audio transmission function. The extender can use for a wide range of applications requiring long distance transmission of high resolution with high quality by its good stability and powerful security.

Feature

1. Transmits DVI video signals up to 2km over a pair fiber optic cable;
2. Support video resolution up to 1920*1200P@60Hz;
3. Support EDID copy function, can match many kind display device;
4. Support remote control switch ON/OFF;
5. Support USB keyboard and mouse signal transmission;
6. Support external stereo audio unidirectional transmission;
7. Compliance with DVI 1.0.
8. High compatibility, can auto-match source and display device;
9. Built-in automatic adjustment system, make the image smooth, clear and stable;
10. Built-in ESD protection system;
11. Simple to install, plug and play

Specification

Model No. LM-THF122DKM

Standards

DVI 1.0;

Maximum pixel clock

165MHz

Maximum data rate

10Gbps

Resolution range

Up to 1920X1200@60Hz

Connector

DVI-D

Impedance

100Ω

Interface

3.5mm earphone seat

Signal type

Stereo

Interface

LC connector

Fiber type

Single-mode a pair fiber

Wavelength

Single-mode 1310nm

Interface bandwidth

10Gbps

Transmission distance

standard 2km

Power supply

The power adapter: DC 12V/1A

Power dissipation

MAX 6W

Temperature

Operating: -5℃ ~+70℃

Humidity

Operating: 5%~90%

Dimension

120*120*30mm

The warranty

1 year free warranty
Note: Specifications are subject to change without notice.

Connection Diagram
DVI Fiber Optic HDMI Extender 2KM LC KVM DVI Extender Over Fiber

Panel Description

DVI Fiber Optic HDMI Extender 2KM LC KVM DVI Extender Over Fiber

FAQ

Q1: Are you a factory or trading company?

A1: As a professional manufacturer, we supply HDMI related products more than 10 years in China.

Q2: Why should we choose you?

A2: We can offer products with factory price, good quality, best service and long warranty.

Q3: How about your product service?

A3: We can offer OEM and ODM, print your brand, your design on the product based on your order quantity.

Q4: How about the payment terms?

A4: We accept bank transfer, western union, money gram, paypal, Bank of China or cash as payments.

Q5: How do you ship the package?

A5: DHL, Fedex, EMS, by air, by sea...etc.

Q6: What kinds of warranty do you offer?

A6: Our excellent after-sale service team will provide you technical support online. We offer one year warranty for our products.

Q7: How could I buy the products I need if there is no price on the website?

A7: You can send us your inquiry about the products you need. Our sales will reply you within 24 hours to help you make the order.

User Manual:

LM-THF122DKM DVI Fiber Optic Extender.pdf
