Mini DVI Fiber Optic Extender with 2KM Transmission Distance 10.2Gbps Video Bandwidth and HDMI 1.3 Compatibility
Mini DVI Fiber Optic Extender with 2KM Transmission Distance 10.2Gbps Video Bandwidth and HDMI 1.3 Compatibility
Mini DVI Fiber Optic Extender with 2KM Transmission Distance 10.2Gbps Video Bandwidth and HDMI 1.3 Compatibility
Mini DVI Fiber Optic Extender with 2KM Transmission Distance 10.2Gbps Video Bandwidth and HDMI 1.3 Compatibility
Mini DVI Fiber Optic Extender with 2KM Transmission Distance 10.2Gbps Video Bandwidth and HDMI 1.3 Compatibility
Mini DVI Fiber Optic Extender with 2KM Transmission Distance 10.2Gbps Video Bandwidth and HDMI 1.3 Compatibility
Mini DVI Fiber Optic Extender with 2KM Transmission Distance 10.2Gbps Video Bandwidth and HDMI 1.3 Compatibility
Mini DVI Fiber Optic Extender with 2KM Transmission Distance 10.2Gbps Video Bandwidth and HDMI 1.3 Compatibility
Specifications
Fuselage Shell :
Zinc alloy shell
HDMI Compatible :
HDMI 1.3
Video Bandwidth :
10.2Gbps
Transmission Distance :
2KM
Brand Name :
VINCAN
Model Number :
WL-209TR
Certification :
CE,FCC and RoHs
Place of Origin :
Mainland China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T,PayPal
Supply Ability :
100 pcs per week
Delivery Time :
2-3 days
Packaging Details :
Carton box and standard export package
Supports :
RGB, YCbCr4:4:4 4:2:2, YUV4:2:0
Electrostatic Protection :
Human body model: ±8kV (air discharge), ±4kV
product name :
fiber optic extender
Output Port (Transmitter) :
1 x FIBER
Description
Mini 1 Channel DVI1080P HD Video Optical Extender With External Stereo Audio DVI Fiber Extender
Product Overview

The MINI DVI fiber optic extender is a compact solution designed for long-distance high-speed transmission of DVI/HDMI video signals. This device supports EDID learning for compatibility with various display resolutions and features USB power supply capability, allowing convenient power sourcing from projectors, displays, or video processing equipment.

Utilizing single-mode optical fiber transmission up to 2KM, this extender offers compact size, easy installation, and low heat generation.

Key Features
  • Compliant with HDMI 1.3 and DVI 1.0 specifications
  • Supports 10.2Gbps video bandwidth
  • Maximum video resolution: 1920x1200@60Hz
  • Transmitter supports EDID learning
  • HDMI audio transmission support
  • 3D format video compatibility
Technical Specifications
Video Compatibility HDMI 1.3 / DVI 1.0
Video Bandwidth 10.2Gbps
Video Resolution 480i to 1080p50/60Hz, 1920x1200@60Hz; HDMI resolution up to 4K30HZ backward compatible
Color Space RGB, YCbCr 4:4:4 / 4:2:2, YUV 4:2:0
Color Depth 8/10/12-bit (1080P60Hz)
HDMI Audio Format LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD
Transmission Distance 2KM (single-mode optical fiber only)
Electrostatic Protection Human body model: ±8kV (air discharge), ±4kV (contact discharge)
Transmitter Ports Input: 1 x DVI-D [19-pin female], 1 x Micro USB
Output: 1 x FIBER
Receiver Ports Input: 1 x FIBER, 1 x Micro USB
Output: 1 x DVI-D [19-pin female]

This uncompressed DVI fiber optical extender transmits signals up to 2KM without compression.

Applications

The SDI fiber optic extender is widely used in various large-scale multimedia applications including:

  • Video recording and high-definition display systems
  • Information release centers and news centers
  • Traffic guidance and information display systems
  • Outdoor large screen display systems
  • Stage displays and entertainment centers
  • TV live broadcast and multimedia conferences

This versatile solution supports real-time video feeds for strategic guidance and coordination, demonstrating reliability in critical environments. The SDI fiber optic extender is essential for any application requiring high-quality video transmission over long distances in modern multimedia setups.
