Mini 4 Channel Sdi Multiviewer Quad 4 Channel 3g Sdi Multiviewer
Mini 4 Channel Sdi Multiviewer Quad 4 Channel 3g Sdi Multiviewer
Mini 4 Channel Sdi Multiviewer Quad 4 Channel 3g Sdi Multiviewer
Mini 4 Channel Sdi Multiviewer Quad 4 Channel 3g Sdi Multiviewer
Specifications
Brand Name :
VINCAN
Model Number :
WL-MVP9104
Certification :
CE,FCC and RoHs
Place of Origin :
Mainland China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
100 pcs per week
Delivery Time :
2-3 days
Packaging Details :
Carton box and standard export package for Mini 4 Channel Sdi Multiviewer Quad 4 Channel 3g Sdi Multiviewer
SDI Input Connector :
BNC complies with IEC169-8
AUDIO Input :
1 set of XLR balanced audio cannon input/1 channel analog audio input
Weight :
2.1KG
HDMI Output Signal :
Standard HDMI signal
Output Signal :
HD-SDI HD serial digital video signal
SDI Output Connector :
BNC complies with IEC169-8
Power Supply Range :
100-240V/AC 50/60Hz
Response Frequency :
550-3.6KHz, < +/-3dB
Description
Features:
1. Half 1U body design, can be a single device on the rack, or two devices can be assembled into a
standard 1U;
2. Support single screen full screen, PIP, POP, multiple 3-screen division, 4- screen division;
3. Support LCD status display (multi-screen split mode, channel signal detection alarm, etc.);
4. Support character overlay, size and position color can be customized;
5. Support LCD status display (multi-screen split mode, current channel signal status, etc.);
6. Input OSD, audio column display;
7. Output port: SDI × 4 loop output; SDI × 2 / HDMI × 1 multi-screen split output.;
8. The output supports multiple resolution switching.;
9. Input 3G/HD/SD SDI Adaptive;
10. Support control panel shortcut control;
11. Support network, RS422 control;
12. Support network upgrade system function;
13. Special features can be customized;

Technical Parameters:
HDMI Output Rate 270Mbps~2.97Gbps
SDI Input Rate 143Mbps~2.97Gbps
SDI Output Impedance 75Ω
SDI Input Connector BNC complies with IEC169-8
Working Humidity 20%~70%RH
SDI Input Reflection Loss >15dB 5MHz~3GHz
SDI Output Reflection Loss >15dB 5MHz~3GHz
Output Signal HD-SDI HD serial digital video signal
SDI Input Impedance 75Ω
HDMI Output Signal Standard HDMI signal


Packing and Shipping:

Product Name: HDMI Multiviewer

Description: Enjoy seamless multitasking with this HDMI multiviewer that allows you to display multiple sources on one screen.

Package Includes: HDMI Multiviewer, Power Adapter, User Manual

Features: - Supports up to 4 HDMI input sources - Customizable display layouts - Remote control for easy operation - High-definition output resolution

Shipping Information: - Shipping Method: Standard Shipping - Estimated Delivery Time: 3-5 business days - Shipping Cost: Free
